Controls And Display - Cameo STUDIO PAR 64 LED CAN Manuel D'utilisation

4
POWER OUT
Neutrik powerCON power output socket. Used
to supply power to additional CAMEO projectors.
Make sure that the total current consumption in
amperes (A) of all connected devices does not
exceed the specified value on the device.
5
FUSE HOLDER
IMPORTANT INFORMATION: Replace the fuse only
with a fuse of the same type and rating. If the fuse
blows repeatedly, please contact an authorised
service centre.
6
MODE
Selection of the standalone functions, DMX
modes, and DMX address.
7 ENTER
Makes it possible to change a value and confirm
changes.
1
3
5
9
6 7

CONTROLS AND DISPLAY:

2
4
10
8 8
UP AND DOWN BUTTONS
8
Press the UP and DOWN buttons, for example, to
change the microphone sensitivity, stroboscope
speed or DMX address.
9 LIT LC DISPLAY
Displays the operating mode and values of
individual functions. The illumination of the LC
display switches off automatically after approx.
70 seconds of inactivity. Pressing any one of the 4
control buttons will turn the illumination of the LC
display on again.
10 EYELET FOR SAFETY CABLE
Overhead installation may only be carried out by
trained personnel. The spotlight must be secured
with an appropriate safety cable to prevent falling.
7
