Item Ref. No.
1 56384385 BOLT, CARRIAGE, 3/8" X 1-1/4"
2 56002063 WASHER, FLAT, 3/8"
3 56002951 NUT, LOCK, 3/8"
4 56001858 BOLT, HEX, 3/8" X 1-1/4"
5 56384383 WASHER, LOCK, 3/8"
6 56002063 WASHER, FLAT, 3/8"
7 56384320 REGULATOR, LP, ASM.
8 56002093 BOLT, HEX, 1/4" X 1"
9 56384378 WASHER, LOCK, 1/4"
10 56002098 WASHER, FLAT, 1/4"
11 56384309 BATTERY, 12V
12A 56384347 BELT, BX-41 (21")
12B 56384279 BELT, BX-53 (27")
13A 56384300 PADHOLDER, 21", ASM.
13B 56384306 PADHOLDER, 27", ASM.
14 56384274 RETAINER, PAD
15 56384298 SPACER
16 56384319 STRAP, 2" X 23"
17 56384316 SLIDE, STRAP
18 56384348 PAD, TANK
19 56384288
CYLINDER, STEEL, LP
For cleaning machines, parts & supplies click/visit www.southeasternequipment.net
Description Qty
3
3
3
3
3
3
1
2
2
4
1
1
1
1
1
1
1
3
1
2
1
D11
Main Assembly (continued)
