C
D
C
4-1/2"
10" (25.4 cm)
(11.4 cm) D.
8" (20.3 cm)
4" (10.2 cm)
A
Roofing Nail Location (4 total)
Emplacement pour clou pour toiture (4 total)
Lugar para clavo de techar (4 en total)
D
C
C
4-1/2"
(11.4 cm) D.
A
Roofing Nail Location (5 total)
Emplacement pour clou pour toiture (5 total)
Lugar para clavo de techar (5 en total)
Roughing-In - 7210 - 7213, 7220 - 7223 Series
NOTE: The diagram shown above is representative and for use with table below.
A
72100100/72200100
36" (91.4 cm)
72110100/72210100
42" (106.7 cm)
72120100/72220100
48" (121.9 cm)
72130100/72230100
60" (152.4 cm)
IMPORTANT! All dimensions are nominal. The stud opening tolerance is +1/8" (3
mm)/-0. Carefully measure your fixture before determining enclosure size. Some
shimming between the stud frame and the fixture may be required. If a firewall is
required, rough-in dimensions will have to increase according to the thickness of the
firewall material. Stud opening dimensions must be measured toward the exposed
side of the wall material. Dimensions given in the rough-in information are crucial for
proper installation. Construct the framing and plumbing accurately.
The stud locations must meet load bearing requirements, which are often specified by
local building codes. Studs must also allow for the installation of the plumbing fixtures
and shower doors.
The receptor and optional wall surrounds can be installed directly to the framing studs,
over wallboard, or over other water-resistant material. When installing over wallboard or
other water-resistant material, increase the framing dimensions to accommodate the
material thickness.
If installing this fixture with a shower door, refer to the shower door manufacturer's
instructions for any special framing considerations.
1064904-2-A
15-13/16" (40.2 cm)
26" (66 cm)
3-1/4"
(8.3 cm) D.
B
10" (25.4 cm)
26"
8"
(66 cm)
(20.3 cm)
4" (10.2 cm)
8" (20.3 cm)
B
C
18" (45.7 cm)
10" (25.4 cm)
21" (53.3 cm)
13" (33 cm)
24" (61 cm)
16" (40.6 cm)
30" (76.2 cm)
16" (40.6 cm)
6
35-1/4"
(89.5 cm)
A
77"
(195.6 cm)
D
16" (40.6 cm)
16" (40.6 cm)
16" (40.6 cm)
14" (35.6 cm)
Sterling
