4. Technical data

Engine displacement
Maximum engine capacity
Bar length
Cutter rail length
Chain pitch
Chain thickness
Idling speed
Maximum speed with cutting equipment
Chain speed max.
Tank capacity
Oil tank capacity
Anti-vibration function
Chain wheel teeth
Chain brake
Clutch
Automatic chain lubrication
Low-kickback chain
Net weight without chain and chain bar
Net weight (dry)
Fuel consumption (specific)
LPA sound pressure level (ISO 22868)
KPA uncertainty
LWA sound power level measured
(ISO 22868)
KWA uncertainty
LWA sound power level guaranteed
(ISO 2000/14/EC)
Ahv vibration (front handle)
(ISO 22867)
Khv uncertainty
Ahv vibration (rear handle)
(ISO 22867)
Khv uncertainty
Chain type OREGON 91PJ052X (91P053X)
Bar type OREGON 140SDEA041 (140SCEA041)
Spark plug
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
n
37.2 cm 3
order.
1.2 kW Service and clean the appliance regularly.
n
Adapt your working style to suit the appliance.
n
32 cm
Do not overload the appliance.
n
14" (35 cm)
Have the appliance serviced whenever
n
(3/8"), 9,525 mm necessary.
Switch the appliance off when it is not in use.
n
(0.05"), 1.27 mm
Wear protective gloves.
n
3100 ± 300 rpm
11000 rpm

5. Before starting the equipment

21 m/s
310 cm 3
210 cm 3
Important: Do not start the engine until the saw
is fully assembled.
Yes
6 teeth x 9.525 mm
Important: Wear protective gloves at all times
when handling the chain.
Yes
Yes
5.1 Fit the chain bar
Yes
To ensure that the bar and the chain are supplied
with oil, USE ONLY THE ORIGINAL BAR. The oiling
Yes
hole (Fig. 2/Item A) must be kept clear of dirt and any
4.5 kg
build-up of residue.
5 kg
1. Make sure the Chain brake lever is pulled back
into the DISENGAGED position (Fig. 3A)
560 g / kWh
2. Remove the two bar fastening nuts (B). Remove
100 dB(A)
the cover (Fig. 3B).
3. Using a screwdriver, run the adjustment screw (D)
2.5 dB(A)
COUNTERCLOCKWISE until the TANG (E)
(projecting prong) is to the end of its travel toward
110.9 dB(A)
the clutch drum and sprocket (Fig. 3B/3C).
4. Fit the open end of the chain bar over the die bar
2.5 dB(A)
pins (F) (Fig. 3C/3D).
112 dB(A)
5.2 To install saw chain
1. Spread chain out in a loop with cutting edges (A)
pointing CLOCKWISE around loop (Fig. 4A).
max. 5.46 m/s 2
2. Slip the chain around the sprocket (B) behind the
1.5 m/s 2
clutch (C). Make sure the links fit between the
sprocket teeth (Fig. 4B).
3. Guide the drive links into the groove (D) and
max. 6.21 m/s 2
around the end of the bar (Fig. 4B).
1.5 m/s 2
NOTE: The saw chain may droop slightly on the lower
part of bar. This is normal.
L8RTF
4. Pull the chain bar forward until the chain is closely
seated. Make sure that all the drive links are in the
groove of the bar.
5. Fit the clutch cover and fasten it with 2 screws.
Make sure that the pivot (Fig. 3C/Item E) fits into
the chain bar (Fig. 3D/Item G). The chain must
GB
