2.22 Thermal fuse

To be able to use the electric wheelchair again, remove the overload and wait till the motor
has cooled down. Then gently press the thermal safety mechanism back in. Your wheelchair
is now ready for use again.
3

Installation and adjustment

The instructions in this chapter are for the specialist dealer only.
The Express VB has been designed as a rear wheel drive electric wheelchair.
L
WARNING:
Risk of unsafe settings - Use only the settings described in this
manual.
L
WARNING:
Risk of tipping over - Variation allowed adjustments can still change
the stability of your wheelchair (tilt back or sideways).
3.1

Tools

To set up the wheelchair the following tools are needed.

Wrench set n° 10

Allen keyset n° 4 to n° 5
3.2

Manner of delivery

The electric wheelchair shall be delivered with:

Framework with armrests, operator unit, rear and front wheels, seat and backrest

1 pair of footrests

2 separate drive batteries + battery housings, 2 x drive motors

Battery charger + manual battery charger

Electronics

Tools

Operator unit + manual operator unit

Accessories
Before use, check that everything is included and that no products are damaged (example
by transport, ...). Please note that the basic configuration may differ in different European
countries. Contact your specialist dealer.
To protect the motor against overload, on the
back of the wheelchair topside of the first battery
housing, there is a thermal safety mechanism 
that will automatically cut off the motor to prevent
overheating and thus rapid wear and tear or
breakdowns. This can occur if you go up or down
slopes that exceed the maximum gradient
indicated. Nominal
maximum could also
mechanism.
Page 22
Express VB
2016-08
loads exceeding the
trigger the safety
