Transit wheels

Transit Wheels (Fig.6.38)
Travel wheels should be used wherever your wheelchair would
be too wide if the rear wheels were used. After the rear wheels
have been removed with the aid of the quick-release axles, the
transit wheels can immediately be used to continue riding. The
transit wheels are mounted so that they are approx. 3 cm above
the ground when not in use. They are thus out of the way when
riding, transporting, or when tipping to pass over obstacles.
CAUTION!
Without rear wheels, your wheelchair has no wheel locks.
Fig.6.38

7.0 Tyres and Mounting

Solid rubber tyres are standard.
With pneumatic tyres always make sure that the tyres have the
correct air pressure, as otherwise the performance of the
wheelchair may be affected. If the tyre pressure is too low,
rolling resistance will increase, requiring more effort to move the
chair forward. Low tyre pressure also has a negative impact on
manoeuvrability. If the tyre pressure is too high, the tyre could
burst. The correct pressure for a given tyre is printed on the
surface of the tyre itself.
Tyres are mounted the same way as an ordinary bicycle tyre.
Before installing a new inner tube, you should always make
sure that the base of the rim and the interior of the tyre are free
of foreign objects. Check the pressure after mounting or
repairing a tyre. It is critical to your safety and to the
wheelchair's performance that regulation air pressure be
maintained and that tyres be in good condition.
22

8.0 Name plate

Nameplates
The name plate is located on either the cross-tube assembly or
the transverse frame tube, as well as on a label in the owner's
manual. The nameplate indicates the exact model designation
and other technical specifications. Please provide the following
pieces of information whenever you have to order replacement
parts or to file a claim:
SAMPLE
Rubix
2
Life R
Rubix
Life R 2
Product Name/SKU Number.
Maximum safe slope with anti-tips fitted,
Depends on wheelchair setting, posture and
physical capabilities of the user.
Seat width.
Depth (maximum).
Load Maximum.
CE Mark
User's Guide.
Crash Tested
Date of manufacture.
VITAL Serial number.
Due to our policy of continuous improvement in the design
of our wheelchairs, product specifications may vary slightly
from the examples illustrated. All weight/dimensions and
performance data are approximate and provided solely for
guidance.
Sunrise Medical complies with the EU Medical Devices
Directive 93/42/EEC
All wheelchairs must be used in accordance with
the manufacturer's guidelines.
