SC TESSERA – OPERATION AND SELECTION OF THE MODES
Switching between operating modes
With the device switched on, press the fire button quickly three times to pull up the menu and click the Fn button
to open the MODE options� Press the setting buttons to switch between the POWER/VW, TC, and TCR functions�
Press the Fn button to confirm each selection and to enter the respective submenu of a mode, if applicable, for
further settings (wattage under POWER, temperature under TCR with M1, M2, or M3)� Press the Fn button to
confirm your selection�
Settings in POWER/VW Mode
In Power mode, the power – depending on the vaporizer head used – can be between 1 and 150 watts� Use the UP
and DOWN button to increase or decrease the power�
Settings in TC Mode
In the TC (Ni, Ti, SS) and TCR (M1, M2, M3) modes, the temperature can be set simply by pressing the UP or DOWN
button after selecting the coil or memory position�
Note:
1� The TC-SS mode is specially designed for the 316 stainless steel coil�
2� The TC/TCR mode supports a maximum of 1�0 ohms� The device automatically switches to VW mode when the
resistance is greater than 1�0 ohms�
3� When Kanthal wire is used in TC/TCR mode, the device automatically switches to POWER mode�
