ENGLISH
55
Chapter 13
OPERATING INSTRUCTIONS

13.1 Main Menu

Selected state
Fig. 13-1-1
Unselected state
Operating instructions
1 Enter corresponding setting interface by touch screen.
2 Use "Up" "Down" "Left" "Right" to move the focus to the wanted submenu
and press confirm key or touch to enter corresponding interface.
3 Click or press return key to return the sample interface.

13.2 Sample Interface

The interface is shown as Fig.13-2-1.
Function introduction
This interface shows waveform. You can modify gain, speed, print mode,
waveform display mode (3-lead, 6-lead, 12-lead), in addition print, set filter
quickly, check sate of SD-card. Operating instructions are as follows:
