The saw unit is now in a central position on the
table and the machine can be used as a table
saw.
8b Circular trimming saw (fig. 3)
fRelease the saw lock by turning the rotary
knob [2-6] anticlockwise.
It can now be used to move the saw unit backwards
and forwards for making cuts. The backwards mo-
tion is supported by a spring force.
8.1 Extra feet [1-3]
Always use the extra feet with an extension table
(width or length) or sliding table.
fLoosen the screw [1-4], swivel the leg
[1-3] down until it has settled on the floor and
retighten the screw [1-4].
8.2 Fitting the accessory holder
See figures 13 and 14.
fWhen connecting the two individual parts,
make sure that the tabs on the latches fit
together exactly and lock in place.
fAlso check the back of the accessory holder to
make sure the latches are in the correct posi-
tion in the holding brackets.
8.3 Cuts along the mitre
For cuts along the mitre, the preset profile set-
ting rail should be on the right-hand side of the
table.
8.4 Switching on the machine when cutting
metal
When cutting metal, switch on the saw using a
residual current circuit breaker.
8.5 Set-up position
Always move the saw into the set-up position be-
fore configuring any settings on the machine:
The saw is locked in the off position upon deliv-
ery.
fTurn the rotary knob [2-6] anticlockwise to
release the lock and pull the saw forwards.
fPush the notch lever [1-9].
The saw is now locked in the middle position.
8.6 Setting the cutting height
To set the cutting height in set-up position any-
where between 0-70 mm:
fTurn the cutting height adjuster [1-10].
L
To ensure a precise saw cut, set the cutting
height 2-5 mm greater than the thickness of
the workpiece.
8.7 Setting the mitre angle
The saw blade can be swivelled between 0° and
45° in set-up position:
fUnscrew the rotary knob [2-4].
fSet the mitre angle using the rotary handle
[2-3] with reference to the scale [2-5].
fTighten the rotary knob [2-4].
For precision trimming work (undercuts on abut-
ting edges), the saw blade can be swivelled out
2° beyond the two end positions.
fTo do this, press and hold the button [2-2] in
the end position.
The saw blade can now be swivelled to -2° or 47°
using the rotary handle [2-3]. Releasing the but-
ton [2-2] reactivates the 0° and 45° stops.
8.8 Changing tools
WARNING
Risk of accident, electric shock
fAlways disconnect the mains plug from the
socket before performing any work on the
machine.
CAUTION
Hot and sharp tools
Risk of injury
fWear protective gloves.
Removing the saw blade
fWear gloves when changing the tool, but not
when cutting.
fLock the saw in set-up position.
fSet the greatest inclination and the maximum
cutting height.
fLoosen the clamp on the insert using the rota-
ry knob [5-1].
fSlide the clamping plate forwards.
fReach underneath the table insert [1-7] to lift
the back and remove it towards the back of the
table.
fRemove the guard, see section 6.2b.
fTake the hex key [5-3] out of the holder on the
saw blade cover [5-10].
fRelease the locks [5-9] using the rotary knob
and the hex key [5-3] and swivel the saw blade
cover [5-10] downwards.
fInsert the hex key [5-3] into the saw blade
retaining screw.
-
