ELECTRICAL CONNECTION

This tool has a precision-built electric motor. It should be connected to a POWER SUPPLY THAT IS 120 VOLTS, 60 HZ, AC ONLY
(NORMAL HOUSEHOLD CURRENT). Do not operate this tool on direct current (DC). A substantial voltage drop will cause a loss of
power and the motor will overheat. If the tool does not operate when plugged into an outlet, double-check the power supply.

POLARIZED PLUGS

To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the other). This plug will fit in a
polarized outlet only one way. If the plug does not fully fit in the outlet reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. Do not change the plug in any way.

EXTENSION CORDS

When using a power tool at a considerable distance from a power source, be sure to use an extension cord that has the capacity to
handle the current the tool will draw. An undersized cord will cause a drop in line voltage, resulting in overheating and loss of power.
Use the chart to determine the minimum wire size required in an extension cord. Only round jacketed cords listed by Underwriter's
Laboratories (UL) should be used.
NOTE:
Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
Keep the extension cord clear of the work
area. Position the cord so that it will not get caught on lumber,
tools or other obstructions while you are working with a power
tool. Failure to do so can result in serious personal injury.
Check extension cords before each use. If damaged replace
immediately. Never use tool with a damaged cord, since
touching the damaged area could cause electrical shock
resulting in serious injury.

PRODUCT SPECIFICATIONS

POWER CONNECTIONS

FEATURES

Cutting Capacity
(Maximum nominal lumber
sizes)
Baseboard (Vertical)
Crown (Vertically Nested)
Net Weight
Input
Blade Arbor Hole
Blade Diameter
No Load Speed
** Ampere rating (on total data label)
12A- 16A
Cord Length
25'
50'
** Used on 12 gauge - 20 amp circuit
NOTE: AWG = American Wire Gauge
0° Miter/0° Bevel: 4" x 14" (2 x18") Extended Capacity
45° Miter/ 0° Bevel: 4" x 10"
0° Miter/45° Bevel: 2" x 14"
45° Miter/45° Bevel: 2" x 10"
6.5"
7.5"
57 lbs
120 V~, 60hz, 15 Amps
1"
12"
4,000 r/min (RPM)
6
Wire Size
14 AWG
12 AWG
