Solar station technical data

Parameter
Dimensions
Max. operating temperature
Maximum pressure
Measuring range
Manometer scale
Thermometer scale (flow)
Thermometer scale (return)
Connection
Distance (between flow and return)
Body material
Insulation material
Tightening elements
Medium
6.0

Mounting of the device

GB D
• Remove the top part of the insulation
• Screw the bottom part of the insulation shell to the wall
• Connect the solar station to the shell
• Connect the expansion tank to the safety group
• Connect the supply voltage
• Put the insulation shell back on
The solar station must not be exposed to high temperatures which occur during
welding and soldering. The solar station must be installed after these jobs are done.
It must be ensured to use a solar liquid appropriate for the solar station.
OEG Compact Two-Line Solar Station
Value
440 x 280 x 150
120°C (short-term < 15 at 160°C)
6 bar
1-6 l/min
2-12 l/min
0-10 bar
0-100⁰C
0-160⁰C
R ¾"
97 mm
Brass
EPP
EPDM
Water or water glycol (max. 50%)
