Technical description
MSI900, MSI1300, MSI1800
The inverter has the following connections, displays and control elements on the
front:
No. in
fig. 6,
Label
page 4
1 Main switch
"ON/OFF/REMOTE"
2 "Input Level" LED
3 "Load Level" LED
4 Dip switch
5 Safety socket
MSI1800T
The inverter has the following connections, displays and control elements on the
front:
No. in
fig. 7,
Label
page 5
1 Main switch
"ON/OFF/REMOTE"
2 "Input Level" LED
3 "Load Level" LED
4 Dip switch
5 AC output
6 AC input
7 Fuse
8 Earthing screw
18
Description
Switches the device on, off or to operation via the
remote control (accessory)
Displays the input voltage range
Displays the power being supplied
Makes settings on the inverter (such as mains voltage,
mains frequency, energy-saving mode).
230 V output
Description
Switches the device on, off or to operation via the
remote control (accessory)
Displays the input voltage range
Displays the power being supplied
Makes settings on the inverter (such as mains voltage,
mains frequency, energy-saving mode).
230 V output
230 V input
Protects the inverter from overload.
The fuse can be pressed in again once it has trig-
gered.
Sets or removes the grounding bridge
SinePower
EN
