Manual: RTI FEMTO Series
DMX Address Settings:
Safety Settings I:
Safety Settings II:
Laser Status On-ext:
page 9 / 31
Set up the DMX start value if there is an integrated
grating effect or integrated laser control interface
(FB3SE / MicroNet Slim)
Set up your horizontal safety zone by sliding the
yellow box. The lower part will be the active safety
zone. Use the colour sliders to individually adapt
the colour intensity within the safety zone.
1st row: select if you want to enable / disable the
Safety shutter
2nd row: select if you want to enable / disable the
Shutter signal on ILDA Pin 13
3rd row: select if you want to enable / disable the
Safety Zone you can set up on Safety Setting
4th row: select if you want to enable / disable the
Power Sensor
Select laser OFF to swich off the laser projector
Select Laser ON internal if you have an integrated
laser control interface inside the laser
(FB3SE / MicroNet Slim)
Select Laser ON ILDA in to use the ILDA input signal
