Tool Specifications

Belt sander
Order number
Rated power
Output power
No-load belt speed
Length of sander belt
Width of sander belt
Belt speed preselection
Connection for integrated dust extraction
Weight (without accessories) approx.
Protection class
Please observe the order number of your machine. The trade names of the individual machines may vary.

Machine Elements

1 On/Off switch
2 Lock-on button for On/Off switch
3 Dust box (micro filtersystem)
4 Thread
5 Adjustment screw
6 Belt speed thumbwheel (PBS 7 AE)
7 Recess for screw clamp
8 Holder for dust box
9 Outlet piece
10 Latching lever
11 Filter element (micro filtersystem)
12 Clamping lever
13 Access clip
14 Parallel and angle guide*
15 Screw clamp*
16 Base unit (PBS 7 AE SET)
* Not all of the accessories illustrated or described are
included as standard delivery.

Noise/Vibration Information

Measured values determined according to
EN 50 144.
Typically the A-weighted noise levels of the prod-
uct are: sound pressure level: 89 dB (A); sound
power level: 102 dB (A).
Wear ear protection!
The typical hand/arm vibration is below 2.5 m/s
9 • 2 610 391 096 • TMS • 04.02.02
PBS 7 A
0 603 391 0..
[W] 600
[W] 300
[m/min] 250
[mm] 457
[mm] 75
–
•
[kg] 2.4
/ II

For Your Safety

Working safely with this ma-
chine is possible only when the
operating and safety information
are read completely and the in-
structions contained therein are
strictly followed. In addition, the
general safety notes in the en-
closed booklet must be ob-
served. Before using for the first
time, ask for a practical demon-
stration.
Wear protective goggles, ear protection and a
dust protection mask.
Wear protective gloves.
For long hair, wear hair protection. Work only
with closely fitting clothes.
If the mains cable is damaged or cut through
while working, do not touch the cable but im-
mediately pull the mains plug. Never use the
machine with a damaged cable.
Connect machines that are used in the open
via a residual current device (RCD) with an ac-
tuating current of 30 mA maximum. Use only
extension cables that are approved for outdoor
use.
Always direct the cable to the rear away from
the machine.
Insert the mains plug only when the machine is
switched off.
Apply the machine to the workpiece only when
2
switched on. Switch off the machine only after
.
it has been lifted from the workpiece.
Always switch the machine off and wait until it
has come to a standstill before placing it down.
English - 1
PBS 7 AE
0 603 391 7..
600
300
170 – 250
457
75
•
•
2.4
/ II
