5.2 Technical data
Max. operating pressure
Min. inlet pressure at
+70 °C/+95 °C/+110 °C
* The pump is equipped with a power limiting function which provides protection
against overload. This can have an effect on the output depending on operation.
5.3

Scope of delivery

• Complete circulation pump
• including thermal insulation shell
• Wilo-Connector included
• Installation and operating instructions

6 Description and function

6.1 Description of the product
The pump (Fig. 1/1) consists of a hydraulic system, a glandless
pump motor with a permanent magnet rotor, and an electronic
control module with an integrated frequency converter. The
control module includes a red operating knob and an LCD
(Fig. 1/2) for setting all parameters and for displaying the cur-
rent electricity consumption in W, or the effective flow in m³/h
and the cumulative electricity consumption in kWh since com-
missioning.
6.2 Functions
All functions can be set, activated or deactivated using the red
operating knob.
Display of the current power consumption in W.
or
Display of effective flow in m³/h.
