to fully recharge a rechargeable battery – especially in dark, grey and misty months (e.g. October to February).
For temperatures around 0 degrees centigrade or below, we recommend the use of a large 6 V alkaline battery instead
of a 12 V rechargeable battery.
The energizer is operated primarily from the solar panel. If the solar panel does not have sufficient output,
the energizer switches automatically to the connected 6 volt battery or to the 12 volt rechargeable battery.
Various modes can be set with press button 1 (Fig. 5) . The currently set mode is displayed by pressing the button briefly.
All modes can then be selected one by one with each additional button pressing. The mode selected last remains set after
exiting the menu.
Table 2
The following menu items can be selected:
Normal
Normal pulse sequence (1.5 seconds).
SLOW MODE
S low pulse sequence (2.0 seconds) by day and at night Control by APN*
5. Maintenance
Table 12 (6V battery)
Remaining capacity
Flashing
green
light
Flashing
red
5 %
light
Replace the battery at the latest when 95% discharged (only 5% charge capacity left).
The battery indicator (LED2) lights up:
Table 13 (12V rechargeable battery)
Remaining capacity
Flashing light green
red/
20-40%
Flashing light
green
Flashing light red
0-20%
The rechargeable battery must be recharged at the latest when discharged down to 20% (only 80% charge capacity left) to
prevent a flat battery. The rechargeable battery indicator (LED2) lights up:
Do note that temperature and measurement deviation may cause these figures to vary.
Caution!
When using a solar system
Only carry out a battery or rechargeable battery test at start of the day ( no solar power supplied - cover panel )
6
Battery good
15-100%
Battery fully depleted
6V battery - immediately replace
Rechargeable battery good
40-100%
Charge the battery
Rechargeable battery absolute-
ly depleted
6. Disassembly, Dismantling, Storage and Transport
Disassembly, Dismantling
Before starting disassembly:
● Switch off energizer
● Disconnect entire energy supply from the energizer.
● Remove operating/auxiliary materials and any remaining working materials and dispose of in an environmentally-compati-
ble manner.
Then properly clean sub-assemblies and parts and disassemble them in taking account of the local industrial safety &
environmental protection provisions in force.
Storage, Transport
Ensure that the energizer is both stored and transported only when switched off.
NOTE!
Ensure that rechargeable batteries are stored in ventilated and dry rooms.
7. Faults and Repairs
WARNING!
Repairs may only be carried out by qualified persons.
Only the spare parts prescribed by the manufacturer may be used.
Subject to technical alterations!
Table 14
Faults Display
Battery under 15% capacity LED flashes alternately red/green
Battery under 5% capacity LED flashes red
Rechargeable battery under
LED flashes alternately red/green
40% capacity
Rechargeable battery under
LED flashes red
20% capacity
trapper AB12 _ 14497
Corrective action
Change batteries
Change batteries
Charge the battery
Charge the battery
