Step 1: Install the HobbyMaster Energizer
Install under cover, out of reach of children, next to a mains
power outlet. Using the 2 screws provided, screw the mounting
bracket to the wall. Attach the HobbyMaster to the bracket
by hooking it over the 2 prongs and snapping the bottom into
place. Do not switch the energizer on until the fence has been
constructed. To remove, fi rst disconnect from power supply and
then use a slotted screwdriver to release the bottom clip and lift
the HobbyMaster off the wall mount.
Step 2: Install the Earth Stake
Install a galvanized earth stake (at least 60cm long) into the
ground, until only 5cm remain above the earth. The most
effective place for an earth system is in continuously damp soil.
Using double insulated cable (G609 or G627), remove 5 cm of
plastic coating from one end of the cable wire. Press the green
(EARTH) terminal button and insert the wire into the terminal.
Secure the cable to the wall (e.g. with a staple) so the cable does
not put any strain on the energizer terminal. Attach the other
end of the cable to the earth stake using an earth clamp.
Step 3: Install Fibreglass Fence Stakes
Install fence stakes (at least 60cm long and at least 10cm into the
ground). Attach clips to each post at the required height. The
bottom wire should be low enough to ensure that the animal
cannot crawl under the fence without touching the wire. The top
wire should be positioned between chest and nose height of the
animal.
Step 4: Install Insulators
Use Screw-in Ring insulators (G666) or Pinlock insulators (G687) to
insulate the start and end points and the corners.
Step 5: Install the Polywire
Tie Polywire (G621) to the insulators at the start of the fence. Roll
out the Polywire and tie to the insulators at the end of the fence.
Hand tension the Polywire until it is taut (no sag), then attach to
each clip on the fence.
Step 6: Connect Cable to the Fence Terminal
Connect the Energizer's red (FENCE) terminal to the fence using
double insulated cable (G609 or G627). Remove 5cm (2") of
plastic coating from one end of the cable. Press the RED (fence)
terminal button and insert the wire into the terminal.
Step 7: Connect Cable to the Fence
Attach the other end of the cable to the fence. To ensure a good
connection, wrap one loop of the Polywire between the washers
of the Joint Clamp (G603), and insert the cable between the head
and closest washer.
Step 8: Connect to Mains Power Supply and Switch On
Check that the light on the front of the HobbyMaster is fl ashing.
