The equipment may be used only for the tasks it
is designed to handle. Any other use is deemed
to be a case of misuse. The user/operator and not
the manufacturer will be liable for any damage or
injuries of any kind resulting from such misuse.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or indust-
rial businesses or for equivalent purposes.

4. Technical data

Speed n .............................................8,500 min
0
Cutting circle .......................................... Ø 24 cm
Max. operating time ..................... approx. 40 min
Protection class ................................................III
L sound power level ............................ 88.3 dB
WA
L sound pressure level ......................... 68.3 dB
pA
K uncertainty ................................................. 3 dB
Interchangeable battery ..... 18 V d. c. / 1500 mAh
........................... (optional: 18 V d. c. / 3000 mAh)
........................... (optional: 18 V d. c. / 5200 mAh)
Vibration ..................................................5.8 m/s
K uncertainty .......................................... 2.3 m/s²
Weight ....................................................... 2.2 kg
Sound pressure level
at the operator's ear ............................... 78 dB(A)
K uncertainty ................................................. 3 dB
Charging unit
Mains voltage ................... 200-260 V ~ 50-60 Hz
Output
Rated voltage ........................................ 21 V d. c.
Rated current ....................................... 3000 mA
The machine may exceed 85 dB (A). The operator
will require noise protection measures if this is
the case. The noise was measured in accordance
with prEN ISO 10518. The value of the vibrations
emitted by the handle was determined in ac-
cordance with prEN ISO 10518.
Important.
The vibration value changes according to the
area of application of the electric equipment and
may exceed the specifi ed value in exceptional
circumstances.
Anl_GE_CT_18_Li_Kit_SPK7.indb 22 Anl_GE_CT_18_Li_Kit_SPK7.indb 22
GB
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect condi-
tion.
•
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
-1
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
2

5. Before putting into operation

5.1 Fitting the safety hood (Fig. 3-4)
When fi tting the safety hood (Fig. 1/Item 8) make
sure that the edge guide (Fig. 1/Item 6) is in a po-
sition in which the blade head (Fig. 1/Item 7) does
not obstruct the fi tting. Push the guard hood (Fig.
1/Item 8) in the direction of the arrow onto the
motor housing as shown in Fig. 3. Make sure that
it latches in place correctly! Make sure that the
guard hood is fi tted as in Fig. 4.
5.2 Height adjustment (Fig. 5)
Undo the union nut (Fig. 5/Item 5) until the grass
trimmer handle can be moved in and out freely.
Now set the required working height (Fig. 6) and
secure the handle in this position by tightening
the union nut again.
5.3. Fitting the additional handle (Fig. 7)
Fit the additional handle to the mount provided,
paying attention to the teeth (Fig. 7/Item I & II).
Then secure the additional handle with the help
of the screw and the adjustment lock provided.
Make sure that the compartment for the spare
blades faces the top of the equipment.
