TEC30D EV
10.7

Connecting the battery charger

➤ Connect the positive terminal of the battery with the 12 V connection of the
battery charger using a cable with a cross-section of 2.5 mm² (fig. g 7,
page 10).
➤ If the battery to be charged is not also the starter battery, connect the negative
terminal of the battery to be charged to the generator's earth cable (fig. g 6,
page 10).
10.8 Connecting the starter battery
A
NOTICE!
The starter battery must have 12 V and a capacity of at least 60 Ah.
➤ Connect the positive terminal of the battery to the positive battery terminal
connections (fig. g 7, page 10) using a suitable cable:
– cable length < 6 m: cross-section 16 mm²
– cable length > 6 m: cross-section 25 mm²
➤ Fit a 150 A fuse in the positive cable near the positive terminal of the starter
battery to protect the generator's electrical system.
➤ Connect the negative terminal of the battery using a cable with a suitable
cross-section (see above) to the ground connection (fig. g 6, page 10).
➤ Connect the earth connection on the generator to the vehicle chassis.
Remove any paint or rust from the chassis if necessary to ensure good contact.
➤ Protect the connections by applying lubrication.
DE
Connecting the electrical power to the generator
