10. Repair

Warning:
- Repairs shall be made by a skilled electrical engineer.
- When carrying out work on the equipment: de-energise the equipment.

10.1. Replacing the charging head

Unscrew and replace the charging head.

10.2. Replacing the HV resistor

1. Unscrew the charging head.
2. Remove and replace the resistor.
3. Mount the charging head.

10.3. Replacing the HV cable

1. Unscrew the charging head.
2. Remove the resistor.
3. Loosen the adjusting screw of the HV cable pull relief.
4. Slide the cable through.
5. Remove the spring contact.
6. Replace the HV cable.
7. Reassemble the unit in reverse order.

11. Disposal

Adhere to the applicable local environmental and other rules when disposing of the product.

12. Spare parts

Item No.
3927500110
6927500205
6927500600
3927900025
9300906565
9146873900
8009999054
9124976171
Pinner_UM_9752092710_NL_D_GB_F_V2_1
Description
5-point charging head
Linear 6-point charging head
Pinner claw head
Body complete
80 MΩ HV resistor
Spring connector HV 30/60 kV
Flexible gland for spring connector
HV cable
