English–9
Displaying/Adapting Basic Settings
The basic settings can be displayed and changed regard-
less of whether the on-board computer is inserted in the
holder 4 or not. Some settings are visible and changeable
only when the operating computer is inserted. Some menu
items may be missing depending on the equipment of your
eBike.
To access the basic settings menu, press and hold the
"RESET" button 6 and the "i" button 1 until "Configura-
tion" is displayed in text indicator d.
To switch between the basic settings, press the "i"
button 1 on the on-board computer until the desired basic
setting is displayed. When the on-board computer is insert-
ed in holder 4, you can also press the "i" button 11 on the
operating unit.
To change the basic settings, press the On/Off button 5
next to the "–" indicator to decrease the value or scroll
down, or the light button 2 next to the "+" indicator to
increase the value or scroll up.
When the on-board computer is inserted in holder 4, you
can also change the values with the "–" button 12 or the
"+" button 13 on the operating unit.
To exit the function and store a changed setting, press the
"RESET" button 6 for 3 s.
The following basic settings are available:
– "– Clock +": The current time can be set here. Pressing
and holding the setting buttons fast-forwards the setting
speed.
– "– Wheel circum. +": You can change this value pre-set
by the manufacturer by ±5 %. This menu item is dis-
played only when the on-board computer is in the
holder.
– "– English +": You can change the language of the text
indications. You can choose between German, English,
French, Spanish, Italian, Portuguese, Swedish, Dutch
and Danish.
– "– Unit km/mi +": The speed and distance can be dis-
played either in kilometers or miles.
– "– Time format +": The time can be displayed either in
a 12-hour or 24-hour format.
– "– Shift recom. on/off +": You can switch the indica-
tion of a shift recommendation on and off.
– "Power-on hours": Indicates the total travel time with
the eBike (can not be changed).
– "Displ. vx.x.x.x": This is the software version of the
display.
1 270 U20 XBI | (25.4.17)
– "DU vx.x.x.x": This is the software version of the drive
unit.This menu item is displayed only when the on-board
computer is in the holder.
– "DU xxxxxxxxx": This is the serial number of the drive
unit. This menu item is displayed only when the on-
board computer is in the holder.
– " Service MM/YYYY": This menu item is displayed
when the bike manufacturer has set a fixed service
appointment.
– " Serv. xx km/mi": This menu item is displayed
when the bike manufacturer has set a fixed service ap-
pointment after a certain mileage has been reached.
– "Bat. vx.x.x.x": This is the software version of the
battery pack.This menu item is displayed only when the
on-board computer is in the holder.
– "1. Bat. vx.x.x.x": When using 2 battery packs this is
the software version of one of the battery packs. This
menu item is displayed only when the on-board com-
puter is in the holder.
– "2. Bat. vx.x.x.x": When using 2 battery packs this is
the software version of the other battery pack. This
menu item is displayed only when the on-board com-
puter is in the holder.
Power Supply for External Devices via USB
Connection
With the USB connection, it is possible to operate and
charge most devices whose power supply is possible via a
USB port (e.g., various mobile phones).
A prerequisite for the charging is that the on-board com-
puter and a sufficiently charged battery pack are inserted in
the eBike.
Open the protective cap 8 of the USB port on the on-board
computer. Connect the USB connection of the external de-
vice to the USB port 7 on the on-board computer using the
USB charging cable Micro A – Micro B (available from your
Bosch eBike dealer).
Once the consumer has been disconnected, the USB con-
nection must be sealed again carefully with the protective
cap 8.
 A USB connection is not a waterproof plug-in connec-
tion. When riding in the rain, an external device must
not be connected and the USB connection must be
completely sealed with the protective cap 8.
