Installation and Operating Instructions
CHAPTER 1
GENERAL INSTALLATION
AND OPERATING
INSTRUCTIONS
m
+
IMPORTANT
MultiZoneBox - KWL-MZB
1 .0

General information

In order to ensure complete and effective operation and for your own safety, all of the following instructions should
be read carefully and observed. The relevant national standards, safety regulations and instructions (e.g. DIN EN VDE
0100) as well as the technical connection conditions of the energy supply company must be observed and applied.
The planning office provides the planning documents necessary for system calculations. Additional information or a
detailed plan (chargeable service) can be requested from Helios Ventilatoren.
Please keep the installation and operating instructions for reference. The document must be issued to the operator
(tenant/owner) after the final assembly.
1 .1

Warning and safety instructions

The adjacent symbol is a safety-relevant warning symbol . All safety regulations and/or symbols must be abso-
lutely adhered to, so that any dangerous situation is avoided .
1 .2

Important technical information

The unit may only be operated in a technically perfect condition, risk and safety-consciously according to its intended
use.
1 .3

Warranty and liability claims

In order to safeguard warranty and liability claims, the following information must be observed:
– Implementation according to the installation and operating instructions for the unit.
– The use of accessories, which are not approved, recommended or offered by Helios, is not permissible. Any damages
are excluded from the warranty.
If these instructions are not observed, all warranty claims are excluded. This also applies to any liability claims extended
to the manufacturer.
1 .4 Regulations – Guidelines
If the product is installed correctly and used to its intended purpose, it conforms to all applicable regulations and CE
guidelines at its date of manufacture.
1 .5

Intended use

The unit is intended for the supply and extract ventilation of living spaces and buildings in combination with a central
ventilation system. The unit is not a ready-to-use product and it can only be operated once it has been properly installed
and connected to the ventilation system.
The unit may only be installed in frost-free rooms above +5 °C as standard.
In case of operation under more difficult conditions, such as high humidity, heavy contamination, excessive strain due
to climatic, technical, electronic influences, consultation and approval are required because the standard version is not
suitable for this.
Any use other than the intended use is prohibited! The conveying of solid matter or solid matter content > 10 μm in
air and liquid is not permitted. Transport media, which affect the fan materials, and abrasive media are not permitted.
1 .6

Scope of delivery

The delivery consists of one box containing the MultiZoneBox KWL-MZB (check type with delivery note), the mains plug
and the installation and operating instructions.
1 .7

Shipping

The unit is packed ex works in such a way that it is protected against normal transport strain. Carry out the shipping
carefully. It is recommended to leave the unit in the original packaging until installation to prevent any possible damage
and contamination.
1 .8

Receipt

The shipment must be checked for damage and correctness immediately upon delivery. If there is any damage,
promptly report the damage with the assistance of the transport company. If complaints are not made within the agreed
period, any claims could be lost.
1 .9

Storage / Warehousing

Please keep the unit dry and dust-free in protected spaces.
When storing for a prolonged time the following steps should be taken to avoid damaging influences: Protection by dry,
air-dustproof packing (plastic bags with drying agent and moisture indicators). The storage place must be waterproof,
vibration-free and free of excessive temperature variations. Damages due to improper transportation, storage or com-
missioning must be verified and are not liable for warranty.

1 .10 Functional description

The KWL ® MultiZoneBox is used for the individual ventilation control of connected zones (apartment, office, commercial
unit) in combination with a central ventilation system. The unit consists of a supply air chamber and an extract air cham-
ber. The chambers are equipped with a measuring orifice and a volume flow control damper. The volume flow control
dampers can be controlled separately. Large sound insulation elements ensure quiet ventilation operation. The KWL
MultiZoneBox can be controlled via the control element Eco (KWL-MZB-BE) or the control element Touch (KWL-MZB-
BET). A sensor for humidity (KWL-MZB-F) and a sensor for mixed gas and air quality (KWL-MZB-VOC-F) are available
for demand-controlled, automatic operation.
1
EN
