3 .2 .1 Software structure overview
Current values
Ventilation
Sensor
Firmware version
Errors
Configuration
Unit
Ventilation
Sensor
Service level
Saved
configuration
Load from file
Save to file
ï Ventilation level
ï Setpoint Volume flow Supply air
ï Setpoint Volume flow Extract air
ï Volume flow Supply air
ï Volume flow Extract air
ï Shutter position Supply air
ï Shutter position Extract air
ï Humidity (RH)
ï Air quality (VOC)
ï Main version
ï Side version
ï Current errors
ï Error history
Unit name
Unit info
Unit address
Control element
Function Switch contact
Minimum ventilation level
Basic ventilation
Ventilation level 1
Ventilation level 2
Ventilation level 3
Adjust Volume flow Supply air Basic ventilation
Adjust Volume flow Supply air Ventilation level 1
Adjust Volume flow Supply air Ventilation level 2
Adjust Volume flow Supply air Ventilation level 3
Adjust Volume flow Extract air Basic ventilation
Adjust Volume flow Extract air Ventilation level 1
Adjust Volume flow Extract air Ventilation level 2
Adjust Volume flow Extract air Ventilation level 3
Duration Ventilation level 3
Selection
Sensor sensitivity
Explorer
Explorer
8
Value input
Value input
Value input
No control element
Control element Eco
Control element Touch
Deactivated
Collective alarm
External error
Ventilation level 0
Basic ventilation
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
Value input
ï No sensor
ï Humidity sensor
ï Air quality sensor
ï Low
ï Medium
ï High
