INSTALLATION MANUAL
DIGIWAY PLUS
Step II allows you to set all the basic parameters of the operator, according to the type of door to automate Step II allows you to set all the basic parameters of the operator, according to the type of door to automate
The submenu CONFIGURATION consists of 18 parameters. The submenu CONFIGURATION consists of 18 parameters.
Each parameter can have 2 or more values. Each parameter can have 2 or more values.
For each parameter there is a preset factory value. If the function FACTORY DEFAULT of the main menu is used, all the parameters are For each parameter there is a preset factory value. If the function FACTORY DEFAULT of the main menu is used, all the parameters are
reset to those values. reset to those values.
See the description of each parameter in the following table: See the description of each parameter in the following table:
Parameter
Num. Doors
Electrolock
Opening Jolt
Push & Open
Push & Close
Wind Stop
Autoreclosing
Radar 'I' Mode
Radar 'E' Mode
Day / Night
Disabled Mode
Open Command
Mode Spring
2 Doors Overlap
Door Type
Arm Type
Fire Signal
ATTENTION : Any change carried out needs a complete cycle ( open, pause, close ) or a system reset ATTENTION
implemented. . implemented
cdvi.com
14
cdvigroup.com
STEP II: CONFIGURATION
Description
Sets the number of Doors
Enables electrolock
Enables the opening Jolt : short pulse of closing before
opening. Usefull to unlock the electrolock in windy
situations
Opens automatically the door with a short push.
Closes the door with a short push even in pause status.
Keeps the door closed in presence of wind which
pushes the door. See Advanced Sets how to set the
level of the closing force used.
Enables the automatic reclosing of the door
Disables the INTERNAL radar input while the door is
closing.
Disables the EXTERNAL radar input while the door is
closing.
Set the Night / Day mode. In Night mode the External
radar is disabled.
Disabled access mode ( See paragraph Disabled
access settings)
Functions of the main command which can open, close
and stop ( this will be the function assigned to the open
button ( terminals 15-16 ) and to the radio transmitter
Spring function: if the door is closed, it remains free
and can be pushed manually; once open the door will
reclose after the pause time set.
Overlap of the leaves ( in case of double doors )
Leaf MASTER or leaf SLAVE ( in case of double doors )
Articulated or sliding arm. The controller sets automati-
cally the best value of the internal parameters according
to the arm type selected
Fire signal management. When this option is enabled
the door operates regularly only if the fi re power V-/V+
is present. If the fi re power falls down ( for a fi re alarm in
progress) the door reacts according to the choice set in
the advanced sets options )
: Any change carried out needs a complete cycle ( open, pause, close ) or a system reset to be
Option
ONE DOOR / TWO DOORS
NO LOCK / ENABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
NEVER / CLOSING / ALWAYS
NEVER / CLOSING / ALWAYS
DAY & NIGHT / NIGHT
ENABLE / DISABLE
OPEN - OPEN/CLOSE -
OPEN-CLOSE/STOP
ENABLE / DISABLE
ENABLE / DISABLE
MASTER / SLAVE
SLIDING / ARTICULATED
ENABLE / DISABLE
EN
Default
ONE DOOR
NO LOCK
DISABLE
ENABLE
ENABLE
DISABLE
ENABLE
NEVER
NEVER
NIGHT
DISABLE
OPEN/CLOSE
DISABLE
DISABLE
MASTER
SLIDING
DISABLE
to be
