Dolomite® Alpha
Adjusting the height
1. Untighten the lever A.
2. Adjust the arm support to a suitable height.
3. Tighten the lever.
WARNING!
Risk of falling
– Do not set the arm support above the highest
position, indicated by the marking B on the
tubes.
Adjusting the angle
1. Untighten the lever A.
2. Adjust the angle of the handles to a suitable position.
Make sure that the handles
are always in the allowed
adjustment area (maximum
20° inwards).
Do not turn the handles
outwards.
3. Tighten the lever.
12
0° max. 20° max. 20° 0°
Adjusting depth and inclination angle
Alpha Basic
A
Alpha Advanced
B
A
C
B
