5 Maintenance

5.3 Cleaning the exhaust filter

12
13

5.4 Spare parts and accessories

ATTENTION:
Only use original spare parts from the scope of delivery or those that you
have purchased by reordering.
If you require accessories and spare parts:
Contact: Page 48, "International Service"

5.5 Before you send in the appliance

WARNING:
Danger of injury! Never use a defective appliance! Always switch off the
appliance and disconnect it from the mains before starting troubleshoot-
ing Chapter 4.3, "Switching off".
Before contacting or even sending the appliance to us, use the following ta-
ble to check whether you can correct the problem yourself.
Problem
Cleaning in- The dust container is full.
dicator
Empty the dust container,
(Fig. 1/6)
dust container".
lights up or
The filters are dirty.
cleaning re-
Clean the respective filter
sults are not
container and motor protection filter" or
satisfactory.
"Cleaning the exhaust filter".
Nozzle, telescopic tube or suction hose is blocked.
Remove the obstacle. If necessary, use a long wooden
stick (e.g. a broomstick) to do this.
A
A
Solution
Chapter 5.1, "Emptying the
Chapter 5.2, "Cleaning dust
Chapter 5.3,
Check the exhaust filter every time you clean the motor protection filter
B
Chapter 5.2, "Cleaning dust container and motor protection filter" and
clean it if it is dirty.
1. Switch off the appliance,
2. Push the release catch of the exhaust filter cover down (Fig. 12/A) and
open out the exhaust filter cover.
3. Remove the exhaust filter (Fig. 12/B).
4. Hold the exhaust filter over a dustbin.
5. Remove any residual dust by tapping. If the exhaust filter is still dirty,
thoroughly rinse it by hand until all dirt is gone.
ATTENTION:
The filter is washable, but it may not be cleaned in dishwashers or wash-
ing machines. Also, do not use detergents or brushes with hard bristles
B
to clean them. Let the filter dry for approx. 24 hours at room temperature
after washing it. Only put it back in place when it is completely dry.
6. If the exhaust filter is damaged, replace it ( Chapter 5.4, "Spare parts
and accessories").
7. Now, put the exhaust filter holder with the freshly fitted filter back into
its bracket (Fig. 13/A).
8. Attach the exhaust filter cover at the bottom side first (Fig. 13/B) before
folding it up firmly. You will feel and hear it snap into place.
The following accessories and spare parts can be reordered:
Item number
2818001 Motor protection filter set consisting of: 1 foam plastic filter
element (round) + 1 filter holder = 1 dual motor protection
filter; 1 small motor protection filter
2818002 1 exhaust filter
M203 1 parquet brush
M209 1 turbo brush
M219 1 mini turbo brush
Problem
The results The bypass vent (Fig. 1/20) is open.
are unsatis-
Close the bypass vent (Fig. 1/20).
factory in
The attached nozzle is unsuitable.
spite of the
Change the nozzle,
appliance
nozzle".
working cor-
rectly
The position of the 'carpet/hard floor' selector (Fig. 1/27) is
(cleaning unsuitable.
indicator
Set the "carpet/hard floor" selector (Fig. 1/27) to the cor-
(Fig. 1/6)
rect position for the type of floor,
does not
cleaning", step 4.
light up).
The vacuum Overheating protection has tripped (possibly because you
cleaner ignored the lit cleaning indicator for too long).
stops sud-
Switch the appliance off and pull the plug out of the socket.
denly.
Eliminate the cause of overheating (e.g.
"Cleaning dust container and motor protection filter"). Wait
for about 45 minutes. After the appliance has cooled off,
you may switch it on again.
NOTE:
If you were unable to solve the problem using the information in the table
above, contact Customer Service (contact
vice").
Chapter 4.3, "Switching off".
Description
Solution
Chapter 3.2, "Selecting the proper
Chapter 4.2, "Vacuum
Chapter 5.2,
Page 48, "International Ser-
15
