Technical Data; Type Label - BWT Infinity A 3/4" Instructions De Montage

EN
12

Technical Data

Infinity A und AP
Nominal connection width
Throughput at ∆p = 0.2 bar
Throughput at ∆p = 0.5 bar
Output pressure downstream of
pressure reducer with connec-
ting module or connection piece
Lower/upper admission
width
Nominal pressure (PN)
Operating pressure,
min./max
Water / ambient tempera-
ture, min. - max
Power supply
Power consumption during
backwashing
AP: CIC dry contact, swit-
ching capacity
Connection type
PNR = production
number Infinity A
PNR = production
number Infinity AP
30
Typ 3/4"
DN 20
m /h 4
3
m /h 7
3
bar
µm
bar
bar
°C
V/Hz
W
Hydromodul-connection
1
2
3
1" 11/4"
25 32
5 5.5
7.5 9
2,5
90 / 110
16
2.5 during backwashing / 16
5 - 30 / 5 - 40
230/50/60 (unit operation at 24 V-)
8
max. 24 V / 1 A (resistive load)
6-082039
6-082041
12.1

Type label

The type label serves as product identifier. In case
of any requests, please have the following infor-
mation ready:
1. Device name
2. Serial number / Year of manufacture
3. Production number / Order-no.
Note: The type label is an official document and
must not be altered or stripped off. Dama-
ged or unreadable type labels have to be
replaced.
11/2" 2"
40 50
10 10
16 16
Four-hole flange
6-082040
6-082042
