Adjustment of a safety threshold and a "Wire rope slack" threshold

3.4.
This configuration is particularly designed to detect a "Wire rope slack" situation or "presence of a
minimum load" below which the signal generated by the micro switch will be processed, for example,
to stop the down movement of the lifting hook.
Preliminary conditions:
- Load limiter correctly mounted and wired.
- Adjustment screws unscrewed to the maximum.
- Hook free of any load.
Equipment required:
A load (called "WLL") equivalent to 100% of the nominal capacity authorized for the lifting
-
machine.
An additional load equivalent to 10 % of the "WLL".
-
A load "X" equivalent to the value of the "Wire rope slack" threshold.
-
ACTIONS
Lift the two loads (100 % + 10 %
1
WLL) by about 10 cm.
2 Adjust the safety threshold S1.
3 Check correct operation.
Lift the intermediate load "X" +150
4
daN ( hysteresis)
5 Adjust the intermediate load S2.
6 Check correct operation.
REMARKS
The additional 10 % represents the overshoot value
authorized in accordance with the European
directives.
Gradually screw in the threshold adjustment screws
(§ 2.1, rep G) until the NC contact opens (see § 3.1).
Use an ohmmeter, for example, to check the state of
the contact.
It must be possible to lift the "WLL" load.
It must be possible to lift the "WLL" load + 10 %.
Depending on the lifting speed, the dynamic effect
may produce an unintentional overload. In this case,
consult with a technician capable of integrating a
signal filtering device (example: time-out, etc.).
Wait for the load to stabilize before adjusting the
threshold.
Gradually screw in the threshold adjustment screws
(§ 2.1, rep. G) until the NO contact closes (see §
3.1.).
Use an ohmmeter, for example, to check the state of
the contact.
Check that the micro switch for threshold S2 trips
when the "Wire rope slack" condition is reached.
