When the engine is switched off, the
connected cooler/warmer box draws power
from the vehicle battery, discharging it. If the
battery voltage drops too low, you will no
longer be able to start the engine.
Remove the 12V power cable (Fig. 2 / Item 18)
from the front pocket and connect it to the 12V
DC socket (Fig. 2 / Item 16) at the rear of the
cooler/warmer box. Turn the power controller (Fig.
8 / Item 8) to the desired position.
6.5 18V Power supply
Push the Power X-Change battery into the battery
mount as described in "Fitting the battery". Turn
the power controller (Fig. 7 / Item 8) to the desired
position.
Battery capacity indicator on the cooler/
warmer box
The battery capacity indicator (Fig. 7 /Item 12)
shows the charge status of the battery using 3
LEDs.
All 3 LEDs are lit
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED fl ashes
The battery is empty, recharge the battery.
6.6 Power controller (Fig. 7 / Item 8)
Note: The power controller clicks audibly as soon
as the cooler/warmer box is switched on or off .
a) "OFF" position: the cooler/warmer box is
switched off .
b) "ECO" position: the cooler/warmer box
consumes low amounts of energy (minimum
cooling or heating capacity).
c) "MAX" position: the cooler/warmer box
consumes the most energy (maximum
cooling or heating capacity).
Turn the power controller knob toward the "MAX"
position to increase the cooling or heating
capacity.
Turn the power controller knob toward the "ECO"
position to decrease the cooling or heating
capacity.
In cooling mode, the interior temperature may be
up to 68°F (20°C) lower than ambient temperature
(77°F) (25°C), to a minimum of 41°F (5°C).
Anl_TE_COL_18_27_Li_NA_SPK7.indb 14
Anl_TE_COL_18_27_Li_NA_SPK7.indb 14
EN
In heating mode, a maximum interior temperature
of 131°F +/- 41°F (55°C +/- 5°C) can be achieved
(at 77°F (25°C) ambient temperature).
6.7 Tips for saving energy
•
Do not leave the cooler/warmer box in the sun
in cooling mode.
•
Use commercially available frozen cooling
elements for additional cooling or to speed up
the process.
•
Only place previously refrigerated food and
drinks into the cooler/warmer box in cooling
mode.
•
Leaving the lid open for prolonged periods
can lead the temperature inside the cooler/
warmer box to rise considerably.
•
Let warm food and drinks cool down before
placing them in the cooler/warmer box to
keep them cool.
•
After a long period in operation, the cooling
capacity can usually be reduced.
7. Cleaning and maintenance
Danger!
Always disconnect the power cable from the
socket outlet, the 12V cable from the plug and
remove the battery before starting any cleaning
work.
7.1 Cleaning
•
Clean the inside of the cooler/warmer box
with dish soap and clean water. Dry the inside
of the cooler/warmer box thoroughly.
7.2 Replacing the fuse in the 12V plug (Fig. 9)
Replace the fuse (T 6.3A) inside the 12V power
plug if it becomes defective. Unscrew and remove
the top end of the plug and replace the defective
fuse with one of the same type. Screw the top end
of the plug back in place.
7.3 Maintenance
There are no other parts inside the equipment
which require maintenance.
