Control panel
15
14
13
No. Designation
8 On/off switch
9 Heating-up phase
indicator
10 Heating ready
indicator
11 Pump indicator
12 Magnetic lock for the
protective flap
13 Controller for the
turbine
14 Controller for the
pump
15 Protective flap
B - 16
12 11 10 9
Meaning
For switching the device on or off
Is illuminated when the device
heats up
Is illuminated when the device has
heated up a is ready for operation
Is illuminated if the pump is active
and fog emerges
Keeps the protective flap (15)
closed
Controls the turbine speed
Controls the flow rate of the pump
Protects the elements of the
control panel against inadvertent
adjustment
Technical data
Parameter
Model
1
Weight without fluid
Dimensions
(height x width x depth)
Evaporator power
Fan turbine power
8
Power consumption, max.
Supply voltage
Type of protection
Air flow rate
Approved fluid
Fluid quantity
Fluid consumption at
maximum output
Fluid consumption at
continuous fog output
Fogging time at max. stage Approx. 210 seconds of
Heating time
Operating conditions
Storage conditions
Scope of delivery
• 1 x Device FS 200
• 1 x 5 m fog transport hose (plastic DN 38)
• 1 x Connector with GEKA coupling
• 1 x 5 l of Fluitect fog fluid in canister
• 1 x Connecting hose fluid canister
• 1 x Quick guide
Optional accessories
• Aluminium end connectors for poly flat roof
• Aluminium end connectors for flat bitumen roof
• Fluitect fog fluid (5 l in canister)
• Flue gas chamber and coloured smoke cartridges for fire
simulation
• Transport case (trolley)
Fog and flue gas simulator FS 200
Value
FS 200
14 kg
465 x 253 x 310 mm
1,500 W
1,600 W
3,100 W
230 V / 50 Hz
IP 54
Approx. 68 l/s (approx. 245 m
Trotec FluiTect fog concentrate
5 l
100 ml/min
30 ml/min
continuous fog output
After approx. 7 minutes
5 °C to 45 °C with less than
80 % RH
5 °C to 45 °C with less than
80 % RH
3
/h)
