Warning
Let the turbine coast for approx. 20 seconds on the
medium level to transport remaining fluids from the
device. The fluid pump must be switch off completely
to prevent the pump from running dry!
Warning
Do not use the device without air filter, for otherwise
the turbine could be damaged due to penetrating
foreign objects.
Notice
Directly behind the outlet opening the emerging fumes
are very hot and, if handled incorrectly, this could
result in the hose material melting or being damaged
otherwise!
In order to avoid heat accumulation in the hose directly
behind the fog outlet opening, the first metre of hose
must not be bent, but instead be laid in a straight line
from the generator!
Notice
Do not operate the device without fog fluid!
Without fog fluid, the pump can be damaged.
Notice
Only use FluiTect fog concentrate from Trotec.
Other fog fluids can damage the device.
Notice
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Notice
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The device serves the purpose of creating artificial fog by
means of fog fluid.
The fog fluid is sucked in by a pump and then heated. With the
integrated high-performance turbine and the thus producible
pressure the fog can be introduced both over long distances
(e. g. sewage pipes, large halls) and in installations with high
counter-pressure (e. g. flat-roofed constructions). Possible
application purposes are for example leak detection, fire brigade
training exercises, quality inspections and tightness tests.
EN
Device depiction
7
6
5
4
2
No. Designation
1 Transport handle
2 Holder for fog fluid canister
3 Air vent with filter
4 Connection for fog fluid canister
5 Power cable
6 Fog transport hose connection
7 Control panel with protective flap
Fog and flue gas simulator FS 200
1
2
3 3
3
