SECTION A: INSTALLATION INFORMATION

FRAMING DIMENSIONS

Model A
16.0"
BF45DXP
(40.5cm) (114.3cm)
16.0"
BF39STP/DXP
(40.5cm)
15.0"
BF33STP/DXP
(38.1cm)
Figure 1
Rough-In Framing Dimensions
This fireplace is a zero clearance design, with the exception of the top of the unit, where any insulation and vapor barrier
should be placed a minimum of 2" (5.1 cm) from the unit. No combustibles can be placed on the top surface of the fireplace.
CAUTION: Ensure installation does not allow fireplace to be in direct contact with building vapor barrier or insulation and
meets all local building code.
Four mounting flanges on the sides of the unit are provided to facilitate installation.

MOUNTING FLANGES

There are two mounting flanges located on each side of the fireplace insert.
From the inside of the unit, bend tabs outward and mount to the inside of the framing using suitable hardware.
4
B C
D
-0 / +0.1 -0 / +0.1
32.9" 30.1"
45"
(83.6cm) (76.5cm)
32.9" 30.1"
39"
(99.1cm) (83.6cm) (76.5cm)
33.1" 28.7" 25.7"
(84.1cm) (72.9cm) (65.3cm)
Air Intake Slots
Figure 2
E F G
15.3" 42.0" 44.7"
(38.9cm) (106.7cm) (113.5cm)
15.3" 36.0" 38.7"
(38.9cm) (91.4cm) (98.3cm)
14.3" 29.6" 32.8"
(36.3cm) (75.2cm) (83.3cm)
Firebox Dimensions
H I J
22.8" 32.7" 60.0"
(57.9cm) (83.1cm) (152.4cm)
22.8" 32.7" 54.0"
(57.9cm) (83.1cm) (137.2cm)
18.8" 28.5" 48.0"
(47.8cm) (72.4cm) (121.9cm)
K
J
Rough-In Corner Framing
Mounting
Flanges
K L
42.0" 42.0"
(106.7cm) (106.7cm)
38.0" 38.0"
(96.5cm) (96.5cm)
34.0" 34.0"
(86.4cm) (86.4cm)
L
