EN
Brush / Pad Weight
(in cleaning mode)
(in cleaning mode)
Brush 18.95 g/cm
12.5 kg
Pad 20.10 g/cm
Vac Motor
Clean Tank
Capacity
Max Power
100W
2.2 L
*Run Time
*Recharge Time
(Battery life)
*1 Hour (80%)
*60-80 Min
*2 Hours (100%)
PROBLEM
Machine will not operate
Vacuum will not operate
Poor water pick-up
No brush / scrub function
Little or no water ow
Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or
Brush / Pad
Cleaning Area
Pressure
2
1320 m
@ 3 km/h
2
Waste Tank
Capacity
3 L
Dimensions
Width = 520 mm
Length = 450 mm
Height = 1140 mm - 1200 mm
*Run and Recharge times may vary dependent on ambient temperature.
CAUSE
Battery not connected
Low battery charge
Vacuum not turned on
Waste-water tank full
Clogged / blocked squeegee hose
Loose hose connections
Separator lter clogged / blocked
Poor separator seal
Damaged separator seal
Damaged / split vacuum hose
Damaged oor-tool blades
Low battery charge
No brushes tted
Brush overloaded
Clean-water tank empty
Incorrect water ow setting
Blocked clean water tank outlets
Numatic Technical helpline +44 (0)1460 269268
Speci cations
Brush Motor
Power
/Hour
2
2 x 200W
Gross Weight
Water
(With liquid &
Ingress
battery)
IPX3
25.5 kg
Hand Arm
Trouble Shooting
SOLUTION
Connect battery (page 25)
Charge battery (page 55)
Turn on vacuum (page 32)
Empty waste-water tank (page 43)
Remove and clean (page 15)
Push tight connections (page 15)
Clean (page 39)
Clean and re t (page 39)
Renew (Spare parts page 118)
Renew (Spare parts page 118)
Renew (Spare parts page 118)
Recharge battery - see battery charger manual
Check and t (page 15)
Reset the machine and decrease the brush load
Fill clean-water tank (page 21)
Adjust uid control levers (page 25)
Remove and clean (page 39)
57
57
Brush Speed
Brush / Pad Width
2 x 220mm
140 rpm
Nett Weight
(No liquid & No
battery)
21.3 kg
Sound Pressure (LpA)
Uncertainty (KpA)
Vibration
≤ 70 dB(A)
≤ 2.5 m/s²
±0.5 dB
(440mm)
Rating
500W
