EN
CONTENTS
● Owner Manual
● Battery Charger & Lead
● Battery Pack
● Scrub Brushes x 2
● Squeegee Assembly
Main tank assembly removal
1
Remove the tank assembly from the front of
the machine. Using the inset handle on the
front of the tank assembly (A), lift the tank
assembly up towards the main handle.
Brush Fitting
Make sure battery is removed before
tting or removing brushes.
Make sure the handle is locked in upright
position and storage wheels are retracted.
Remove the tank assembly (and battery if
tted) gently lay machine on its front
Floor tool and vacuum hose tting
1
Push the oor tool carrier handle down and push the oor tool onto the retaining clips (1 & 2).
Take the hose and t it into the hose retaining clips then push the open end securely over the centre tting on the oor tool. Follow
the arrows for the correct t. Make sure part (A) of the hose stays loose and is not over stretched.
PLEASE READ BEFORE COMMENCING ANY
!
OPERATION AFTER THE REMOVAL OF ALL THE
2
A
Lift and tilt the top of the tank assembly away from the handle as you remove. Place
the tank assembly on a suitable surface in its upright/uppermost position.
1
Push the brush / pad holder onto the
brush motor mounts (1 & 2). Note: Gloves
are recommended to be worn whilst tting
and removing the brushes.
2
Quick Set-up Guide
PACKAGING, CAREFULLY OPEN AND
CHECK THE CONTENTS.
3
2
To remove the brushes, place your ngers
behind the brush deck in locations shown
and gently wiggle o .
3
A
15
15
!
!
