EN
Changing the Floor Tool Blades
!
ALWAYS MAKE SURE THAT THE MACHINE IS SWITCHED OFF AND THE BATTERY IS
A
1
Unscrew the two knobs securing the blade
holder (1).
Re tting the oor tool blades
Re t the blade holder, retain using the two outer knobs. Make
sure the slotted blade goes to the front of the oor-tool.
Re t the oor-tool using the two central knobs to the oor-tool.
Make sure the end holes on both squeegee blades are posi-
tioned correctly on 'T' shaped clip mouldings! (A)
Floor Tool Overview
1. Retaining knobs x 2
2. Front blade (Slotted / Reversible)
3. Blade carrier
4. Rear blade
5. Floor tool main body
NOTE: The blades are designed to be
reversible and rotated giving 4 usable
surfaces (front, back, top and bottom, thus
extending their useful working life).
REMOVED PRIOR TO ANY MAINTENANCE.
B
2
Remove the blade holder (2).
5
4
3
2
49
49
To change the oor-tool, rstly lower the
oor-tool using the left side oor-tool
lowering foot pedal (A).
Pull the oor-tool away from the machine (B).
3
Replace the Squeegee blades using
replacement blade set (Fig.3), tting the
blades on to the moulded location lugs.
A
1
!
