SENA FOR SHARK HELMET
COMMUNICATION SYSTEM
(Available as an accessory/replacement part).
Your helmet is designed to be equipped
with the SENA FOR SHARK (Bluetooth
or Mesh) communication system. If
your helmet is approved according to
UNECE Regulation No. 22-06, it has
also been tested and approved with
SENA FOR SHARK (Bluetooth or
Mesh) installed. The installation of a
system other than SENA FOR SHARK
(Bluetooth or Mesh) compromises
the regulatory compliance of the
helmet. During the installation of the
communication system (see specific
instructions in the SENA FOR SHARK
(Bluetooth or Mesh), kit it will be not
necessary to remove the foam padding
from the helmet (Fig. 31) present in the
polystyrene cheek pads at the housings
of the SENA FOR SHARK (Bluetooth or
Mesh) earphones.
The above-mentioned padding shouldn't
removed when using the helmet with
the compatible SENA FOR SHARK
(Bluetooth or Mesh) system installed.
INSTALLATION OF THE SENA
FOR SHARK SYSTEM
Your helmet is approved for the SENA
FOR SHARK (Bluetooth or Mesh)
system.
26
1 - To do this, remove the textile pad-
-ding (cheek pads and liner) according
to the description of disassembly of the
textile on page 10.
Then remove the 2 side covers on
either side of the carburettor gasket.
(Fig. 32).
2 - Insert the left and right speakers
of the SENA FOR SHARK (Bluetooth
or Mesh) system into the earphone
housings, passing their cable under the
cover covering the polystyrene cheeks
(use the vertical slot on the cheek cover
for this purpose) (Fig 32). In order to
allow the speakers to be held properly,
do not forget to affix the small Velcro
pieces provided in the box of your SENA
FOR SHARK (Bluetooth or Mesh)
system (Fig 33
Fig. 31a
4- Place the microphone and attach it
using the Velcro part provided, and insert
the microphone shaft into the cover of the
Fig. 31b
right polystyrene cheek, using the groove
provided. Connect the extension cable
supplied with the SENA FOR SHARK
(Bluetooth or Mesh) system (Fig. 33).
Fig. 32
Fig. 33
