USING THE THERMOSTAT
THERMOSTAT OPERATION
• Hold Temperature (bypassing the schedule) – With the System Switch
set to Heat or Cool, momentarily press the RUN/HOLD button. Hold will
hold the room temperature at the selected setting until you press RUN/
HOLD to start program operation again.
• Program Override (Temporary Hold)
temperature is displayed. The thermostat will override the schedule until
the next programmed time period with a minimum override of 2 hours.
Then the thermostat will automatically revert to the program.
THERMOSTAT SCHEDULE / PROGRAMMING
Energy Saving Factory Schedule
This thermostat is programmed with the energy saving settings shown in
the table below for all days of the week.
Heating
Schedule
Cooling
Schedule
NOTE: Thermostat can be programmed on or off the subbase.
ENTERING YOUR PROGRAM
Set Current Time and Day
1. Press SET TIME button once. The display will show the hour only.
EXAMPLE:
PM designation (AM begins at midnight; PM begins at noon).
3. Press SET TIME once again. The display window will show the minutes
flashing.
EXAMPLE:
5. Press SET TIME once again. The display will show the day of the week.
7. Press RUN/HOLD once. The display will show the correct time, room
temperature and set-point temperature.
NOTE: Time and set-point will only be shown in heat or cool mode.
8
P1/Wake P2/Leave
6:00 AM - 70°F 8:00 AM - 62°F
6:00 AM - 78°F 8:00 AM - 85°F
P3/Return P4/Sleep
5:00 PM - 70°F 10:00 PM - 62°F
5:00 PM - 78°F 10:00 PM - 82°F
49-5000770 Rev. 1
