Napoleon Riverside Serie Instructions D'installation Et D'utilisation

WARNING
• If the information in these instructions are not followed
exactly, a fire may result causing property damage,
personal injury or death.
• Ensure the appliance, and screen assembly (if installed)
are completely cool before starting installation.
• Do not connect any gas valve or electric module directly
to 110-120VAC power.
• Follow instructions in the appliance's installation manual
for correct wiring procedures. Improper installation
BATTERY WARNING
• Remove and immediately recycle or dispose of
used batteries according to local regulations and
keep away from children. Do NOT dispose of
batteries in household trash or incinerate.
• Even used batteries may cause severe injury or death.
• Call a local poison control center for treatment
information.
• Non-rechargeable batteries are not to be recharged.
• Do not force discharge, recharge, disassemble,
heat above (manufacturer's specified temperature
rating) or incinerate. Doing so may result in injury
Installer: Leave this leaflet with the appliance.
The wall timer is intended to replace the manual ON/OFF switch that comes
standard with the appliance and is equipped with the following buttons:
• 30 MIN: Appliance will operate
for 30 minutes and then turn off
automatically.
• 60 MIN: Appliance will operate
for 60 minutes and then turn off
automatically.
• 120 MIN: Appliance will operate
for 120 minutes and then turn off
automatically.
• OFF: Will manually turn off the appliance.
Replacement Batteries:
Batteries:
Two 3V Button Cell Batteries (CR-2032)
Follow the information provided in this leaflet exactly to install and remove the batteries.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 0G8 Canada · 1(866)820-8686 · www.napoleon.com
Riverside/Galaxy Series Outdoor Timer Kit
Installation and Operation Instructions
• The wall timer operates on two 3V
button cell batteries (included). When
any of the buttons on the wall timer
are pressed, an indicator light on the
timer's face will illuminate to verify the
signal has been sent. (Fig. 1)
• If the signal light does not illuminate
or becomes dim, check/replace the
batteries.
Output:
Dry-Contact for up to 800 m V DC
or 24 VAC.
of electronic components can cause damage to the
electronic module, gas valve, and the remote receiver
(if applicable).
• Any modifications to this outdoor timer or any of its
components will void the warranty and may pose
a fire hazard.
• The timer should not be used with the weather cover
kit (RSS36/42WC) installed. If the weather cover is
installed, the gas supply must be shut off.
due to venting, leakage or explosion resulting in
chemical burns.
• Ensure the batteries are installed correctly
according to polarity (+ and -).
• Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-
zinc, or rechargeable batteries.
• Always completely secure the battery
compartment. If the battery compartment does
not close securely, stop using the product, remove
the batteries, and keep them away from children.
Consumer: Retain this leaflet for future reference.
!
Fig. 1
W415-10001595 | B-0 | 07.23.24
