Applying Grease (Fig. W)
The DCBS681 needs to be greased after every 100 hours
of use.
1. Using a 5 mm hex wrench (not included), remove the
grease port screw and motor grease port screw
44
2. Apply a small amount (3-5 grams) of D
grease
46 into the ports as shown in Fig. W.
3. Reinstall the port screws
wrench (not supplied) to tighten the screws.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk of eye
injury, always wear ANSI Z87.1 approved eye protection when
performing this procedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These chemicals
may weaken the plastic materials used in these parts. Use a
cloth dampened only with water and mild soap. Never let any
liquid get inside the tool; never immerse any part of the tool
into a liquid.
Accessories

WARNING: Since accessories, other than those offered by
D WALT, have not been tested with this product, use of such
e
accessories with this product could be hazardous. To reduce
the risk of injury, only D WALT‑recommended accessories
e
should be used with this product.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact D
(1‑800‑433‑9258) or visit our website: www.dewalt.com.

WARNING: The use of any accessory not recommended
by D WALT for use with this appliance could be hazardous.
e

WARNING: Do not use any blades, or any accessory or
attachment other than those recommended by D
this trimmer. Serious injury or product damage may result.
Replacing the Brushsaw Cutting Blade (Fig. A, I)

WARNING: To reduce the risk of serious personal injury,
turn unit off and remove the battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start‑up can cause injury.
When replacing the brushsaw blade
diameter blades. Use D WALT replacement blade model
e
number DWZBS681. Other sizes may degrade performance
or cause damage to the brushsaw.
Removing the Cutting Blade

WARNING: Use gloves and proper eye protection. Be
careful of the sharp edges of the blade.
1. Remove the battery.
2. Using pliers (not supplied), remove the cotter pin
the shaft 32 .
3. Align the spindle plate hole
insert the locking rod 14
the hole. Hold the locking rod
4. While holding the locking rod
the flange nut 34 by turning it clockwise with the blade
wrench or a 19 mm wrench (not supplied) as shown in
15
Fig. I.
WALT 30301914
e
44 and 45 , using a 5 mm hex
WALT. Call 1‑800‑4‑D
e
WALT on
e
, use 10" (254 mm)
17
with the notch
30 31
or a screwdriver (not supplied) into
14 or a screwdriver in position.
14 or a screwdriver, remove
5. Remove the blade spacer
the spindle plate
for damage and replace if necessary.
Installing the New
.
45 1. Install the spindle plate
the teeth of the spindle align with the slots of the spindle
plate
29 .
2. Install the brushsaw blade
spindle plate
3. Align the spindle plate hole
locking rod
locking rod
4. Install the blade spacer
wide flat side faces the blade.
5. Install the flange nut
spacer and securely tighten with the blade wrench
35
a 19 mm wrench (not supplied).
6. Use the blade wrench
(not supplied) to tighten the flange nut
against the blade spacer
rod 14 or a screwdriver:
‑ If using a torque wrench and an 19 mm socket, tighten to:
325 -335 in-lb, 27 - 28 ft.-lb, 37 - 38 Nm.
‑ Without a torque wrench, use the blade wrench
or a 19 mm closed-end wrench or 19 mm socket and
ratchet, turning the nut until the blade retainer is snug
against the shaft bushing. Ensure that the blade is installed
correctly, then rotate the nut an additional 1/4 to 1/2
turn counterclockwise.
7. Remove the locking rod
spindle plate hole and notch
WALT
e
8. Using pliers (not included), install the cotter pin
the shaft 32
Repairs
The charger and batteries are not serviceable. There are no
serviceable parts inside the charger or battery pack.

WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should be
performed by a factory service center or an authorized service
center. Always use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRAnTY sERViCE: Registering your product will help
you obtain more efficient warranty service in case there is a
problem with your product.
• COnFiRMATiOn OF OWnERshiP: In case of an
insurance loss, such as fire, flood or theft, your registration of
ownership will serve as your proof of purchase.
• FOR YOUR sAFETY: Registering your product will allow
us to contact you in the unlikely event a safety notification is
33 from
required under the Federal Consumer Safety Act.
Register online at www.dewalt.com/account‑login.
and
, brushsaw blade
35
as shown in Fig. I. Examine all pieces
29
Brushsaw
29 onto the shaft
17 onto the shoulder of the
29 as shown in Fig. I.
30 and notch
14 or a screwdriver into the hole and hold the
or a screwdriver in position.
14
35 on the blade
34 with the flange against the blade
or a 19 mm wrench
15
35 while holding the locking
14 or a screwdriver from the
31 .
.
