3.5 To remove fasteners
Warning! Make sure that the battery is not
attached.
Warning! Remove the fasteners from the magazine
before the product is put away.
1
Push the lock button. (Figure 4)
2
Pull back the magazine cover.
3
Remove the fasteners from the magazine.
4
Push the magazine cover forward until it clicks in
position. Make sure it is correctly locked.
3.6 To remove blocked fasteners
Warning! Make sure that the battery is not
attached.
Caution! The product will not start if the firing
mechanism is blocked.
1
Push the lock button. (Figure 4)
2
Pull back the magazine cover.
3
Remove the blocked fastener. If necessary use a
nail or other object to remove the fastener.
3.7 To adjust the operation depth
Note! Hard materials and long nails will need more force
to operate the nail.
Figure 6
● Turn the adjuster knob to the left to increase the
operating depth.
● Turn the adjuster knob to the right to decrease the
operating depth.
Note! Do a test on a workpiece to find the applicable
depth.
3.8 To do a check of the safety tip
Warning! Do a check of the safety tip before each
use. Do not use the product if the safety tip is damaged.
● The safety tip must be able to move freely. Make sure
it goes back to its fully extended position after it is
pushed in.
3.8.1 To change the safety pad
Warning! Make sure that the battery is not attached
before you remove or replace the safety pad, there is a
risk of serious injury.
● The safety pad prevents marks and damaged on the
workpiece.
1
Pull the safety pad from the safety tip and attach
the new safety pad.
3.9 To adjust the firing mode
Warning! Do not operate the product unless
the outlet for the fasteners is put tightly against the
workpiece.
Figure 7
3.9.1 Single operation mode
This mode is applicable for single and accurate fastener
placement.
● Move the mode selector switch to the left position.
The trigger must be pushed each time to shoot a
fastener when the single operation mode is selected.
Note! The safety tip and the trigger must be pushed
down to operate the product.
3.9.2 Contact operation mode
This mode is applicable for fast and repetitive operation.
● Move the mode selector switch to the right position.
In contact operation mode a fasteners is shoot each
time the safety tip is pushed down against the
workpiece while the trigger is pushed.
3.10 The status indicator
The status indicator will flash when the battery is low, the
magazine is empty, or if a fastener is blocked.
3.11 To use the product at cold
temperatures
Note! The cold temperature can have a negative effect on
the performance and the life of the battery.
● Keep the product as warm as possible before use.
● Operate the product on a workpiece 5–6 times before
use.
EN
SV
NO
PL
DE
FI
FR
NL
11
