● Do not use the product if you are tired, ill, or
EN
intoxicated. This will decrease your vision, alertness,
coordination and judgement.
SV
● Do not let children or persons who do not know the
product to use it.
NO
● Do not use the product if it is damaged.
● Do not make changes to the product.
PL
● Use the product only for its specified function.
2.11.1 Residual risks
DE
There will always be residual risks even if you operate the
product in accordance to the instructions.
FI
The following hazards may occur in connection with the
type and design of this power tool:
● Hearing damage if ear protection is not worn.
FR
● Health injuries as a result from the effect of vibration
on the hands and arms when the product is used over
NL
a long period of time or when it is not used and
maintained correctly.
● Danger due to electromagnetic field generated while
the machine is in operation. Under certain
circumstances, this field may negatively affect active
or passive medical implants.
● In order to decrease the danger of serious or fatal
injuries, it is recommended that individuals who wear
medical implants should consult their doctor and the
manufacturer of the implant before operating the
machine.
3
Operation
3.1
To do before operation
Warning! Before each use, do a check of the
selected mode to prevent the risk of injury.
3.2 To attach and remove a battery
Caution! Make sure that the battery is correctly
attached. If the battery become loose, it can cause
personal injury.
Caution! Do not force the battery in place. If it is
not easy to attach, it is not correctly aligned.
3.2.1 To attach a battery
Figure 2
1
Align the battery to the slots in the casing.
10
2
Push the battery until a clicks is heard.
3.2.2 To remove a battery
1
Push the button on the front of the battery.
2
Pull the battery out from the battery port.
3.3 To adjust the belt clip
The belt clip can be attached on the left or on the right
side of the product.
Figure 3
1
Loosen the screw with a screwdriver.
2
Put the belt clip in the applicable position.
3
Attach the belt clip and tighten the screw.
3.4 To load fasteners
Warning! Make sure that the battery is not
attached.
Warning! Do not point the product at yourself or
other person when you load the product, risk of injuries.
Warning! Make sure that the trigger or interlock
mechanism are not activated when you load the product,
there is a risk of injuries.
Caution! Only use fasteners recommended by the
manufacturer. The use of other fasteners can cause injury
or material damage. Refer to "9 Technical data" on page
12.
1
Push the lock button. (Figure 4)
2
Pull back the magazine cover. (Figure 5)
3
Put the fasteners in the magazine.
4
Push the magazine cover forward until it clicks
into position. Make sure it is correctly locked.
● When you load the magazine with nail fasteners, the
tip of the nail must point down and be set against the
bottom edge of the magazine.
● When you load the magazine with staples, put the top
of the staples against the top edge of the magazine.
