RHX2M
Fig. 2 Electrical connections
DIP
Function
1
Rotation guard
2
Max. speed
3
Direction
4
5
Motortype
6
N L
1
2 3
Mainline
230VAC
4 and 6 closed on alarm
or on 230V supply
RHX2M
ON
OFF
On
Off
200rpm
150rpm
DIP
ON
CCW
CW
1 2 3 4 5 6
RHX2-12M
RHX2-14M
OFF
RHX2-16M
4
5 6
7 8 9 10 11
Alarm
Relay
© 2016 OJ Electronics A/S
Status
ON
Flash
light
Purging
Yellow
Stop
Rotation
Green
On
guard pulse
Rotation
Red
Alarm
guard alarm
Modbus
A
B
Modbus
A- A+ B- B+
12 13
14 15 16 17
M
Stepmotor
RHX2-1xM
Illustrations
47
