PolySafe - Spartendichtelemente und Manschettenstopfen
Beschädigung durch unsachgemäße Lagerung!
Bei unsachgemäßer Lagerung können Sachschäden in erheblicher Höhe ent-
stehen.
• Die Manschettenstopfen und Universal-Dichtelemente vor der Montage vor Be-
schädigungen, Feuchte und Verunreinigungen schützen. Es dürfen nur unbe-
schädigte Teile montiert werden.
• Die Lagerung der Manschettenstopfen und Universal-Dichtelemente muss so
erfolgen, dass diese keinen zu niederen Temperaturen (<5 °C) und höheren
Temperaturen (>30 °C) sowie keiner direkten Sonneneinstrahlung ausgesetzt
ist.
Entsorgung
Sofern keine Rücknahme- oder Entsorgungsvereinbarung getroffen wurde, zer-
legte Bestandteile nach sachgerechter Demontage der Wiederverwertung zufüh-
ren:
• Metallische Materialreste nach den geltenden Umweltvorschriften verschrotten.
• Elastomere nach den geltenden Umweltvorschriften entsorgen.
• Kunststoffe nach den geltenden Umweltvorschriften entsorgen.
• Verpackungsmaterial nach den geltenden Umweltvorschriften entsorgen.
EN Safety Instructions and Information
Target Group
The installation may only be carried out by technical experts.
Qualified and trained individuals carrying out installation must have
• knowledge of general safety and accident prevention regulations as amended,
• knowledge of how to use safety equipment,
• knowledge of how to use hand tools and electric tools,
• knowledge of the relevant standards and guidelines for laying pipes/cables and
for backfilling utility trenches as amended,
• knowledge of the regulations and installation guidelines of the supply company
as amended,
• knowledge of the waterproof concrete directive and building waterproofing
standards as amended.
General information and intended use
In line with their intended use, our products have been developed solely for instal-
lation in buildings made of state-of-the-art materials. Insofar as no express written
confirmation has been provided by us, we do not accept any liability for any other
purposes or purposes going beyond the above.
For warranty conditions, please see our current General Terms and Delivery Condi-
tions. We explicitly draw your attention to the fact that no warranty whatsoever
applies for any subsequent damage occurring as a result of failure to follow the
installation instructions or if our products are used incorrectly or combined with
third-party products.
The sleeve capsare designed to ensure reliable sealing of the sleeve pipe to electric
cables, water pipes, telecommunication lines and district heating cables.
The universal sealing elements are suitable for all utility types – electricity, water,
telecommunications and district heating.
Safety
This section provides an overview of all the main safety aspects for optimum pro-
tection of personnel and a safe installation process.
f there is a failure to observe the instructions and safety information set out here,
this may result in significant hazards
The sealing elements or sleeve caps installation must comply with the relevant
professional association regulations, VDE provisions, national safety and accident
prevention regulations as well as company regulations (work and procedural in-
structions).
The fitter must wear the relevant protective clothing.
Only intact components may be installed.
The following instructions are to be observed prior to installa-
tion of PolySafe sealing elements and sleeve caps:
WARNING!
Risk of injury in the event of improper installation!
Improper installation can result in significant bodily harm and property da-
mage.
• Observe the nationally applicable laying and filling regulations for pipes and
cables.
• Seal the underground and cable substructure well prior to laying pipes or cables
so that the latter cannot subside.
NOTICE!
No sealing due to incorrect installation!
Improper installation can result in damage.
• Utility sealing elements are not fixed settlement points or bearings and there-
fore cannot absorb any mechanical forces.
Art. Nr.: 5090033070 Rev.: 07/2024-03-01
• The cables must be mounted straight in the universal sealing element and must
not be subjected to mechanical stress from any subsequent bend radius.
• Openings that are not required must remain sealed with blind plugs or with the
SD0 sealing element plug.
• There must not be any continuous longitudinal grooves on the cables in the se-
aling area (if necessary, move the cable slightly forwards or backwards until any
longitudinal grooves are no longer visible).
• Cables must be clean and free of soiling.
• In the case of thin-walled or foamed pipes, only tighten the tension straps of
the sleeve caps up to a point at which the pipes are not deformed.
• The norms and directives referred to here are valid in Germany only. In all other
countries, the national norms and directives are to be observed as amended.
• No cleaning agents containing solvent may be used to clean the cable seal. We
recommend using cable cleaner KRMTX.
• For details of other accessories and further information, see www.hauff-tech-
nik.de and the technical data sheets as well as the safety data sheet.
Personnel requirements
Qualifications
WARNING!
Risk of injury in case of inadequate qualification!
Improper handling can result in significant bodily harm and property da-
mage.
• Installation may only be carried out by qualified and trained individuals who
have read and understood these instructions.
Skilled experts
Based on their specialist training, skills, experience and familiarity with the rele-
vant provisions, standards and regulations, skilled experts are able to carry out the
work assigned, independently identifying and avoiding potential hazards.
Transport, packaging, scope of delivery and storage
Safety instructions in connection with transport
NOTICE!
Damage in the event of improper transport!
Significant damage can occur in the event of improper transport.
• When unloading packaging items on delivery and in the course of in-house
transport, proceed with care and observe the symbols on the packaging.
Transport inspection
Inspect the delivery immediately on receipt for completeness and transport da-
mage. In the event of transport damage being visible from the outside, proceed as
follows:
• Do not accept the delivery or only do so subject to reservations.
• Make a note of the extent of damage in the transport documentation or de-
livery note provided by the transporter.
• Submit a claim for every defect as soon as it has been identified.
• Claims for damages can only be asserted within the applicable claim
period.
Scope of delivery
The universal sleeve caps for smooth and corrugated pipes DA75-90,
• MS78U 1x24-52 – Universal sleeve cap, water/electricity
• MS78EW 1x24-40+3x7-13+2x5-8 – Sleeve cap for electricity/water
• MS78K 1x13-21+3x7-13+1x5-13 – Sleeve cap for communication
• MS78 D0 – Sleeve cap for blind sealing
• MS78 zxd – Sleeve cap with individual assignment
are supplied with the following:
• 1 sleeve cap, if necessary incl. blind plug
• 1 or 2 stainless steel tension straps
The universal sealing elements,
• Water SDW 1x32/40/50
• Electricity SDE 1x20-34
• Electricity SDE 1x26-29/36-39/43-46/48-51
• Electricity/communication SDEK 1x26-30+3x5-8+2x7-13
• Communication SDK 1x13-21+3x7-13+1x5-13
• Electricity/communication SDEK 1x25-36+3x7-14+2x5-10
• Two-part sealing elements with stainless steel plate, e.g. water/electricalSDEW
1x32-34/40/43+2x7/10-13
• Blind SD0 (sealing element for blind sealing)
• SDX zxd (sealing element with individual assignment)
are supplied with the following:
• 1 sealing element incl. blind plug
• 1 tab
7
