6. Connect the Ethernet cable to the in-
side of the control panel or the outer
Ethernet port [
7. Feed the cable out of the unit. Roll up
the cable outside the unit.
8. Mount the WiFi adapter in a suitable
position [ Figure
>
The WiFi adapter can be fixed or
screwed in selected positions. We
recommend mounting it on the
side of UltraVent hoods (1), in the
center on the rear of the stand (2)
or mounting on the wall (3).
4.2 Setting up the WiFi adapter
DANGER
High voltages during connection to the
power grid
Danger to life when working with high
voltage.
Work on the switched-on unit with
n
the electrical compartment open
may only be carried out by trained
personnel.
Work on the switched-on device
n
may only be carried out with suitable
protective clothing.
4.2.1 Use as a WiFi client adapter
a The electrical compartment is open.
a The device is switched on.
1. Connect the Ethernet cable of the WiFi
adapter to a computer.
2. Ensure that the WiFi on the computer
is deactivated during the configura-
tion.
6 / 32
Figure 11].
12].
80.51.858_iCombiPro-iCombiClassic-SCC_WiFi-Adapter_IM_US-
Logging in
1. In a web browser, open the address
https://192.168.11.1 or a different pre-
viously set IP address. Accept the nec-
essary certificates.
2. Enter the user name and the password
on the screen. The user name is set as
root and the password as Rational as
standard [ Figure
>
Press the Login button.
NOTE
Change the initial password to prevent
misuse
During the first configuration, set a new
password in the System /
Administration menu.
Connecting the adapter with a WiFi
Access Point
NOTE
The network type during connection
must be taken into account
The WiFi adapter can not be used in a
captive portal (e.g. a guest WiFi) or a
WPA2-Enterprise-based WiFi network.
1. In the Network / WiFi menu, press the
Browse button [
2. Select the desired network. Confirm
the network with the Join Network
button.
3. In the WPA key input line, enter the
WiFi password [
firm the entry with the Submit button.
4. Confirm the entry with the Save but-
ton.
5. Confirm with the Save & Apply button.
4 | Installation
13].
Figure 14].
Figure 15]. Con-
