8.Charging Port
9.LED Battery Status Indicator
10.Battery Release Button
11.On/Off Switch
• Press to turn on
• Release to turn off
12.Dust Cup
13.Dust Cup Bottom Cover Release Button
14.Brush Release Button
Fig. B
Installation
Fig. C-1
Wall Mount Installation
Diagram
1. Paste the mounting template sticker
on the wall. The bottom edge of the
mounting template sticker should be
parallel to and about 107cm from the
ground.
2. Use a power drill with an 8 mm drill bit
to drill a hole into each marker on the
mounting template sticker, then insert a
wall plug into each hole.
3. Align the holes on the mount with the
holes on the wall. Fasten it to the wall
with the included screws.
Fig. C-2
Note:
• The wall mount is an optional accessory.
You can install it based on your needs.
• The wall mount should be installed on a
cool, dry surface with an electrical outlet
nearby. Prior to installing, ensure that there
are no electrical wires or pipes in the space
directly behind installment position.
Charging
Fully charge the vacuum before using it for
the first time.
Note:
• A full charge will take approximately 3.5
hours.
• Using Turbo mode for a prolonged period
will cause the battery to heat up, which
increases charging time. Allow the vacuum
to cool down for 30 minutes before
charging it.
Charging Methods
Charging the vacuum with the charger
Fig. D-1
LED Battery Status Indicator
Low battery
Half battery
Nearly full
Fully charged
Off Blinking
Note: Once the vacuum is fully charged, the
indicator will turn off after 5 minutes, and
the vacuum will enter the energy-saving
mode.
Fig. D-2
How to Use
Working Methods
Select from two working methods for the
vacuum, based on your needs.
Method 1: Discontinuous Cleaning Mode
Press and hold the on/off switch to power it
on, and release it to stop immediately.
Fig. E-1
Method 2: Continuous Cleaning Mode
(Trigger switch lock)
Click the trigger switch lock to switch
to Continuous Cleaning Mode when the
vacuum is running. Then release the on/off
switch to make the vacuum in Continuous
Cleaning Mode.
EN
On
