MN006348A01-AF
Chapter 1: IMPRES 2 Batteries and Chargers
2. Plug the wall power adapter into the appropriate Alternating Current (AC) outlet.
A successful power-up sequence is indicated by a single green blink on the charger indicator. Refer to
the IMPRES 2 Battery Charging Indicators on page
3. Insert a Motorola Solutions-approved battery, or a radio with a Motorola Solutions-approved battery
into the charger pocket.
a. Align the battery contacts with the charger contacts.
b. Press the battery into the pocket, ensuring complete contact.
Once the Motorola Solutions-approved battery is properly seated into the pocket, the charger indicator
illuminates, indicating the charger has recognized the presence of the battery.
4. To remove a radio or Motorola Solutions-approved battery from the charger, pull straight up until the
battery completely clears the charger housing.
1.2
IMPRES 2 Battery Charging Indicators
Table 1: IMPRES 2 Battery Charging Indicators
Status
Charger Power On
Rapid Charging
Charged to 90% or more
Charged to 95% or more
8
8.
LED Indicator
Green for approximately one sec‐
ond
Steady Red
Blinking Green
Steady Green
Description
Successful charger power-up.
Battery in rapid charge mode.
Battery is charged to 90% or
greater capacity.
Battery is charged to 95% or
greater capacity.
