shows 45°)
- lock bevel locking lever N
- check for 45° between blade and table top with a mitre
square h
- if necessary, adjust the 45° block bolt AJ in the same
way as for 90° angle
- tighten block bolt AJ
•
Checking/adjusting parallelism between blade and mitre
gauge slots
! disconnect the plug
- raise the saw blade to the highest position rotating
height adjustment wheel Q CLOCKWISE
- mark a point on the saw blade body
- set a combination square to the edge of the mitre
gauge slot and the ruler touching the marked point
- rotate the saw blade and check the marked point at the
rear of the table j a
- if both measurements are not identical, adjust as
follows:
1. loosen wing nut AR
2. turn adjustment bolt AS CLOCKWISE or
COUNTERCLOCKWISE until the blade is parallel to
the mitre gauge slot j b
3. tighten wing nut AR
•
Checking/adjusting rip fence k
! disconnect the plug
! make sure that the checks/adjustments mentioned
above are performed before performing this
adjustment
! the rip fence must be parallel to the saw blade to
prevent kickback
checking/adjusting rip fence on position 1
- remove protective guard and riving knife assembly D
- raise the saw blade to the highest position by rotating
height adjustment wheel Q CLOCKWISE
- lock the rip fence G to position 1
- slide the fence to touch the blade and lock it
- the blade should contact the fence from front to back
- if not, loosen the fence post (on the back) with double-
ended allen wrench AC and slide it left or right
- firmly tighten the fence post on position 1
- loosen the indicator M with double-ended allen wrench
AC and slide it left or right to align with 0 on the WHITE
scale
- tighten the indicator M
checking/adjusting rip fence on position 2
- lock the rip fence G to position 2
- measure the distance from the blade (front and back)
to the fence
- both measurements should be 101.6 mm
- if not, loosen the fence post 2 (on the back) and slide
it left or right
- firmly tighten the fence post on position 2
checking/adjusting rip fence on position 3
- lock the rip fence G to position 3
- slide the fence to touch the blade and lock it
- the blade should contact the fence from front to back
- if not, loosen the fence post (on the back) and slide it
left or right
- firmly tighten the fence post on position 3
assemble protective guard and riving knife assembly D
! make a few test cuts with scrap material to check
the adjustments
•
Adjusting table insert C l
- the front of the table insert should be flush or a little
below the saw table; the back should be flush or a little
above the saw table
- if needed, the table insert can be adjusted with the 4
set screws (2.5mm hex key, not standard included)
•
Storage/transport
- to store the tool make sure that the end of the rail is not
extruding from the table top side z a
- remove the protective guard and riving knife assembly
D
- lower the saw blade
- wrap the cable around the cable storage hook U
- lift the tool by grasping the transport handle AB with the
table top facing towards you
- the removable components of the tool can be stored as
shown z b-d
! ! the riving knife for non-through cut AB can also
be stored as shown in z b
•
Mounting the table saw to the workbench with the four
mounting holes x a
! ensure the length of the wood screws or lag bolts
is long enough to securely fasten the table saw to
the workbench.
•
Mounting the table saw to a stand x b
Follow operator's manual included with SKIL folding
stand AT (not standard included) to assemble the stand
and install the table saw onto the stand.
APPLICATION ADVICE
•
Only use sharp saw blades of the correct type
- quality of cut improves by the number of teeth
- carbide tipped blades stay sharp up to 30 times longer
than ordinary blades
MAINTENANCE / SERVICE
•
Always keep tool and cord clean (especially the
ventilation slots at the back-end of the motor housing)
! disconnect the plug before cleaning
•
Occasionally clean the area under the saw blade (dust
chute) to prevent dust accumulation
•
Clean saw blade immediately after use (especially from
resin and glue)
! the saw blade becomes very hot during use; do
not touch it before it has cooled down
•
Occasionally oil the points indicated c with SAE 20/SAE
30 or WD40
•
If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should
be carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of the
tool are listed on www.skil.com)
•
Be aware that damage due to overload or improper
handling of the tool will be excluded from the warranty
(for the SKIL warranty conditions see www.skil.com or
ask your dealer)
ENVIRONMENT
23
