a
Table saw
INTRODUCTION
• This tool is intended as a transportable machine for
lengthways and crossways cutting of wood with straight
• cuts as well as angle cuts (horizontal mitre angles of -60°
to +60° as well as vertical bevel angles of -2° to +47° are
possible)
• Read and save this instruction manual 2
• Check whether the packaging contains all parts as
illustrated in drawing 6a, 6b
• Only use the tool when correctly and completely
assembled (be aware that Skil cannot be hold
responsible for tool damage and/or personal injuries
resulting from the incorrect assembly of the tool)
TECHNICAL DATA 1
TOOL ELEMENTS 6a,6b
A Table top
B Mitre gauge slot
C Table insert
D Protective guard and riving knife assembly
E Mitre gauge
F Auxiliary fence/workpiece support
G Rip fence
H Clamping lever
9. __
J Rail locking lever
K Rail drive knob
L Push stick
M Rip fence distance indicator
N Bevel locking lever
15. P Bevel angle indicator __
Q Height adjustment wheel
R On/off switch
S Blade
Dust deflector storage
T
U Cable storage hook
V Storage for mitre gauge
W Dust port
X Wrenches
Y Transport handle
Z Storage for protective guard and riving knife assembly
AA Vacuum cleaner adapter
AB Riving knife for non-through cutting
AC Double-ended allen key
AD Bolt, spring washer and plain washer set
AE Dust deflector
AF Riving knife release lever
AG Push block*
AH Featherboard*
35. AJ Block bolt __
AK Bevel-stop Block
AL Hex rod
AM Jam nut
AN Inner flange
41. __
AP Outer flange
AQ Blade nut
AR Wing nut
AS Adjustment bolt
AT Folding stand*
* Not standard included
1330
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions,
-
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
