Polaris
Cordless Robotic Cleaner FREEDOM
®
5.2
Set Cleaning Mode
Start Cleaning
1. From the main screen, select Cleaning Mode to view
options.
2. Select Cleaning Mode. The factory default cleaning
mode is Floor/Wall.
3. From the Home screen, press the Start button
to begin cycle. The cleaner will start when it detects
water and will cancel the cycle if not submerged after
5 minutes.
NOTE: At the beginning of each cleaning cycle, the robot confirms your
pool parameters (approximately 10 minutes). During this time,
the cleaner does not climb to the waterline.
Cleaning Mode
Select
Floor/Wall
Product or App
Floor
Product or App
SMART
In App
Waterline
In App
SMART Cycle
SMART Cycle calculates a customized cleaning time
optimized for your pool. On the first run of SMART Cycle,
the app counts up as it calculates the optimized cleaning
time.
On periodic SMART Cycle cleaning, the app will count
down from the optimized cleaning time.
NOTE: To Recalculate SMART Cycle, go to the Set Cleaning Mode after
the initial calculation.
5.3
In-App Error Messages and
Troubleshooting
After removal and when connected to WiFi, the app will
display any errors from the previous cleaning cycle.
1. Click on the warning symbol to view troubleshooting
advice on how to fix the issue.
2. Choose Clear Error if you believe you have fixed the
problem and want to re-try. Choose OK if you want to
suspend the cleaner in error mode and work on the
troubleshooting fix at a later time.
5.4
System Settings
Access System Settings by pressing the gear icon in the
upper right hand corner of the app screen.
PLUS | Owner's Manual
™
Section 6. Maintenance
To avoid electric shock and other hazards which could result
in permanent injury or death, disconnect (unplug) the cleaner
from the power source before performing any cleaning and
maintenance.
Runtime
2.5 hrs
1.5 hrs
Figure 20. Charging Caddy Distance to Pool Edge
Calculated
0:45 min
6.1
1. Always dry the cleaner before setting on the charging
2. Clean the charge plates ON the charging station using
Figure 21. Clean the Charge Plates
3. Clean the charge plates UNDER the cleaner using a
4. Rinse the cleaner and charging caddy thoroughly with
5. Dry the cleaner and charging caddy with a towel. DO
6.2
The filter canisters should be cleaned at the end of each
cycle before debris dries.
1. Push the cover lock and lift the cover until it is secured
WARNING
Clean the Cleaner and Charging Caddy
caddy.
a cloth or scouring pad. DO NOT use metal sponges or
brushes and solvents or salt water.
cloth or scouring pad. DO NOT use metal sponges or
brushes and solvents or salt water.
clean water.
NOT leave the cleaner and charging caddy to dry in the
direct sun.
Clean the Filter Canisters
in the vertical position.
ENGLISH
11.5 ft
(3.5 m)
Page 13
