8.2 Overview verified models

In verified weighing systems the access to „P2 mode and „P4 tAr" is locked.
In order to unlock the access, the seal must be destroyed and both contacts of the
printed circuit board [K2] must be short-circuited by a jumper, see chap. 6.11.
Attention:
After destruction of the seal the weighing system must be re-verified by an
authorised agency and a new verification wire/seal mark fitted before it can be
reused for applications subject to verification.
Menu block Menu item
Main menu Submenu
PO CHK SET H
SET LO
Weighing with
tolerance range,
PCS H
see chap. 7.7
PCS L
BEEP
P1 COM MODE
Interface
parameter
baud
Pr
PtYPE
Lab
Prt
SFB-BA-e-1625
Available settings / explanation
Upper limit value „Tolerance check weighing", input see chap. 7.7.1
Lower limit value „Tolerance check weighing", input see chap. 7.7.1
Upper limit value „Tolerance check counting", input see chap. 7.7.2
Lower limit value „Tolerance check counting", input see chap. 7.7.2
Acoustic signal for weighing with tolerance
no
range switched off
Audio sound when load is within tolerance
ok
limits
Audio sound when load is beyond tolerance
ng
limits
Continuous data output
CONT
One output for stable weighing value
ST1
Continuous data output of stable weighing
STC
values
PR1
Output after pressing
Manual totalizing, see chap. 7.8
PR2
Press
added to the summation memory and issued.
AUTO
For automatic totalizing see chap. 7.9. This
function is used to issue and add individual
weighing values automatically to the
summation memory on unloading of weighing
scale.
ASK For remote control commands, see chap. 10.4
wireless
Not documented
Kit 1
Available Baudrate: 600, 1200, 2400, 4800, 9600
7E1
7 bits, even parity
7o1 7 bits, odd parity
8n1 8 bits, no parity
tPUP
Standard printer setting
LP50
Not documented
Lab x
Details see following table 1
Prt x
